Omron PCB Signal Relay, 3V dc Coil, 1A, DPDT
- RS Stock No.:
- 683-9769
- Mfr. Part No.:
- G6KU-2P-Y DC3
- Brand:
- Omron
Currently unavailable
Sorry, we don't know when this will be back in stock.
- RS Stock No.:
- 683-9769
- Mfr. Part No.:
- G6KU-2P-Y DC3
- Brand:
- Omron
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Omron | |
| Product Type | Signal Relay | |
| Coil Voltage | 3V dc | |
| Contact Configuration | DPDT | |
| Mount Type | PCB | |
| Switching Current | 1A | |
| Switching AC Voltage | 125V ac | |
| Switching DC Voltage | 60V dc | |
| Series | G6K | |
| Minimum Operating Temperature | -40°C | |
| Switching Power | 30W | |
| Maximum Operating Temperature | 70°C | |
| Width | 6.5mm | |
| Length | 10mm | |
| Height | 5mm | |
| Terminal Type | Through Hole | |
| Standards/Approvals | RoHS | |
| Contact Material | Gold Plated | |
| Coil Resistance | 91Ω | |
| Coil Power | 100mW | |
| Contact Resistance | 100mΩ | |
| Select all | ||
|---|---|---|
Brand Omron | ||
Product Type Signal Relay | ||
Coil Voltage 3V dc | ||
Contact Configuration DPDT | ||
Mount Type PCB | ||
Switching Current 1A | ||
Switching AC Voltage 125V ac | ||
Switching DC Voltage 60V dc | ||
Series G6K | ||
Minimum Operating Temperature -40°C | ||
Switching Power 30W | ||
Maximum Operating Temperature 70°C | ||
Width 6.5mm | ||
Length 10mm | ||
Height 5mm | ||
Terminal Type Through Hole | ||
Standards/Approvals RoHS | ||
Contact Material Gold Plated | ||
Coil Resistance 91Ω | ||
Coil Power 100mW | ||
Contact Resistance 100mΩ | ||
G6K Series
Fully sealed construction
Low power consumption of approximately 100mW
Sub-miniature, H5.0 x W6.5 x L10mm
G6K-2P types conform to FCC Part 68 (1500V for 10x160μs)
G6K-2P-Y & G6KU-2P-Y types conform to Bellcore specifications (2500V for 2x10μs)
Approvals
UL, CSA
