    Hongfa Europe GMBH PCB Mount Signal Relay, 24V dc Coil, 2A Switching Current, DPDT

    View all Signal Relays

    Subtotal (1 tube of 40 units)*

    £77.44

    (exc. VAT)

    £92.92

    (inc. VAT)

    Add to Basket
    Select or type quantity
    In Stock
    • 1,560 unit(s) ready to ship
    Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
    Units
    Per unit
    Per Tube*
    40 +£1.936£77.44

    *price indicative

    RS Stock No.:
    176-2720
    Mfr. Part No.:
    HFD31/24-S
    Brand:
    Hongfa Europe GMBH
    Find similar products by selecting one or more attributes.
    Select all

    Brand

    Hongfa Europe GMBH

    Coil Voltage

    24V dc

    Contact Configuration

    DPDT

    Mounting Type

    PCB Mount

    Maximum Switching Current AC

    0.5 A

    Maximum Switching Current DC

    2 A

    Maximum Switching Voltage AC

    125V

    Maximum Switching Voltage DC

    110V

    Maximum Switching Power DC

    30 W

    Series

    HFD31

    Latching

    No

    Length

    14.5mm

    Depth

    9mm

    Height

    5.4mm

    Dimensions

    14 x 9 x 5mm

    Terminal Type

    Through Hole

    Switching Current

    2A

    Number of Poles

    2

    Contact Material

    Gold Plated

    Coil Resistance

    2800Ω

    Coil Power

    140mW

    Maximum Operating Temperature

    +70°C

    Isolation Coil To Contact

    1.5kV rms

    Operating Temperature Range

    -40 → +70°C

    Electrical Life

    100000 Operations

    Maximum Switching Power AC

    62.5VA

    Features

    Offers Excellent Board Space Savings, Low Power Consumption, Single Or Double Coil Winding Type Available

    Relay Switching Classification

    Subminiature Signal Relay

    Minimum Operating Temperature

    -40°C

    Life

    1 x 10^8 cycles
