RS PRO Relay, Current, Voltage Input, 12V Supply

View all Signal Conditioners

Subtotal (1 unit)*

£0.48

(exc. VAT)

£0.58

(inc. VAT)

Add to Basket
Select or type quantity
Temporarily out of stock
  • 999,999,999 unit(s) shipping from 26 December 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units
Per unit
1 +£0.48

*price indicative

RS Stock No.:
325-336
Brand:
RS PRO
Find similar products by selecting one or more attributes.
Select all

Brand

RS PRO

Module Type

Relay

Input Signal Type

Current, Voltage

Supply Voltage

12V

Standards Met

cURus E158859, IEC 61810-7, R50044268, TUV, UL

COO (Country of Origin):
CN

RS PRO Signal Relay, 12V dc, 2 Poles, 3A, DIL Pitch Terminal, 20.5 x 10.2 x 12.5mm


This high sensitivity signal relay from RS PRO is designed for reliable performance in various electronic applications. It is fully sealed, ensuring protection against environmental factors, and is ideal for use in audio visual equipment, medical monitoring, and telecommunication systems.

Features and Benefits


DIL Pitch Terminals: Ensures easy integration into circuit boards
High Sensitivity: Provides efficient signal detection and switching
Conforms to FCC Part 68 1.5kV Surge and Dielectric 1000VAC: Offers robust protection against electrical surges
High Reliability Bifurcated Contact: Enhances contact stability and longevity

Applications


Audio Visual Equipment
Flight Simulator
Measuring Instruments
Medical Monitoring Equipment
Office Equipment
Security Alarm Systems
Sensor Control
Telecommunication Equipment

Additional Information


Standards Met: cURus E158859, IEC 61810-7, R50044268, TUV, UL
Operating Temperature Range: -40 to 90°C
Coil Voltage: 12V dc
Contact Material: AgNi
Maximum Switching Power (AC): 125VA
Maximum Switching Power (DC): 90W
Electrical Life: 1x10^5 operations
Dimensions: 20.5 x 10.2 x 12.5mm
Maximum Switching Voltage: 250V ac, 220V dc
Maximum Switching Current: 3A (AC/DC)
