Turck Bi10-EM30-Y1X-H1141 Threaded Barrel Inductive Proximity Sensor, M30 x 1.5 NAMUR BI 10 20V 10 mm 8.2 V dc 1.2mA
- RS Stock No.:
- 819-3153
- Mfr. Part No.:
- Bi10-EM30-Y1X-H1141
- Brand:
- Turck
Subtotal (1 unit)*
£124.84
(exc. VAT)
£149.81
(inc. VAT)
FREE delivery for orders over £60.00
Temporarily out of stock
- 4 unit(s) shipping from 21 August 2026
- Plus 5 unit(s) shipping from 02 November 2026
- Plus 6 unit(s) shipping from 16 November 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £124.84 |
*price indicative
- RS Stock No.:
- 819-3153
- Mfr. Part No.:
- Bi10-EM30-Y1X-H1141
- Brand:
- Turck
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Turck | |
| Thread Size | M30 x 1.5 | |
| Product Type | Inductive Proximity Sensor | |
| Body Style | Threaded Barrel | |
| Length | 62mm | |
| IP Rating | IP67 | |
| Mount Type | Flush | |
| Terminal Type | M12 | |
| Housing Material | 304 Stainless Steel | |
| Width | 18mm | |
| Maximum Supply Voltage | 20V | |
| Maximum DC Voltage | 8.2V dc | |
| Maximum Detection | 10mm | |
| Materials Detected | Metal | |
| Minimum Operating Temperature | -25°C | |
| Maximum Operating Temperature | 70°C | |
| Standards/Approvals | Output acc. to DIN EN 60947-5-6 (NAMUR), É II 1 G Ex ia IIC T6 Ga/II 1 D Ex ia IIIC T115 °C Da, ATEX 1090X, SIL2 as per IEC 61508 | |
| Shielding | Shielded | |
| Maximum Switching Frequency | 500Hz | |
| Output Type | NAMUR | |
| Switching Current | 1.2mA | |
| Series | BI 10 | |
| Select all | ||
|---|---|---|
Brand Turck | ||
Thread Size M30 x 1.5 | ||
Product Type Inductive Proximity Sensor | ||
Body Style Threaded Barrel | ||
Length 62mm | ||
IP Rating IP67 | ||
Mount Type Flush | ||
Terminal Type M12 | ||
Housing Material 304 Stainless Steel | ||
Width 18mm | ||
Maximum Supply Voltage 20V | ||
Maximum DC Voltage 8.2V dc | ||
Maximum Detection 10mm | ||
Materials Detected Metal | ||
Minimum Operating Temperature -25°C | ||
Maximum Operating Temperature 70°C | ||
Standards/Approvals Output acc. to DIN EN 60947-5-6 (NAMUR), É II 1 G Ex ia IIC T6 Ga/II 1 D Ex ia IIIC T115 °C Da, ATEX 1090X, SIL2 as per IEC 61508 | ||
Shielding Shielded | ||
Maximum Switching Frequency 500Hz | ||
Output Type NAMUR | ||
Switching Current 1.2mA | ||
Series BI 10 | ||
- COO (Country of Origin):
- DE
M30 Threaded Barrel Sensors
High quality Turck Banner M30 x 1 threaded barrel stainless steel inductive sensors, providing accurate contactless metal detection. The sensors are available with 10mm or 15mm rated operating distance and flush or non-flush mounting conditions.
Stainless Steel Barrel
IP67 rating
LED status display
Flush mounting
