WIKA MW Series Pressure Switch, SPDT Output 0 bar 16 mbar
- RS Stock No.:
- 269-1251
- Mfr. Part No.:
- 48705397
- Brand:
- WIKA
Subtotal (1 unit)*
£740.86
(exc. VAT)
£889.03
(inc. VAT)
FREE delivery for orders over £60.00
Stocked by manufacturer
- Ready to ship from 21 December 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £740.86 |
*price indicative
- RS Stock No.:
- 269-1251
- Mfr. Part No.:
- 48705397
- Brand:
- WIKA
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | WIKA | |
| Maximum Pressure Measurement | 16mbar | |
| Product Type | Pressure Switch | |
| Minimum Pressure Measurement | 0bar | |
| Accuracy | ±1 % | |
| Output Type | SPDT | |
| Terminal Type | M20 x 1.5 F | |
| Series | MW | |
| Standards/Approvals | RoHS, IECEx-ATEX Ex ia | |
| Housing Material | 316L Stainless Steel | |
| Minimum Operating Temperature | -30°C | |
| Maximum Operating Temperature | 85°C | |
| IP Rating | IP66 | |
| Select all | ||
|---|---|---|
Brand WIKA | ||
Maximum Pressure Measurement 16mbar | ||
Product Type Pressure Switch | ||
Minimum Pressure Measurement 0bar | ||
Accuracy ±1 % | ||
Output Type SPDT | ||
Terminal Type M20 x 1.5 F | ||
Series MW | ||
Standards/Approvals RoHS, IECEx-ATEX Ex ia | ||
Housing Material 316L Stainless Steel | ||
Minimum Operating Temperature -30°C | ||
Maximum Operating Temperature 85°C | ||
IP Rating IP66 | ||
- COO (Country of Origin):
- IT
The WIKA Diaphragm Pressure Switches have been developed especially for safety critical applications. This sensor is traced by quality assurance software at every step and subsequently are 100 percent tested. The robust switch enclosure can withstand the rough and corrosive operating conditions of the process industry.
No supply voltage required
High switching power
