WIKA A-10 Series Pressure Sensor 0 bar 16 bar, Gauge, Vacuum, Absolute Reading
- RS Stock No.:
- 262-7310
- Mfr. Part No.:
- 12794733
- Brand:
- WIKA
Subtotal (1 unit)*
£145.12
(exc. VAT)
£174.14
(inc. VAT)
FREE delivery for orders over £60.00
Stocked by manufacturer
- Ready to ship from 28 September 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £145.12 |
*price indicative
- RS Stock No.:
- 262-7310
- Mfr. Part No.:
- 12794733
- Brand:
- WIKA
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | WIKA | |
| Pressure Reading Type | Gauge, Vacuum, Absolute | |
| Product Type | Pressure Sensor | |
| Maximum Pressure Measurement | 16bar | |
| Minimum Pressure Measurement | 0bar | |
| Accuracy | ±1 to ±2.4 % rdg | |
| Series | A-10 | |
| Standards/Approvals | No | |
| Housing Material | 316L Stainless Steel | |
| Maximum Operating Temperature | 80°C | |
| Minimum Operating Temperature | 0°C | |
| IP Rating | IP65 | |
| Select all | ||
|---|---|---|
Brand WIKA | ||
Pressure Reading Type Gauge, Vacuum, Absolute | ||
Product Type Pressure Sensor | ||
Maximum Pressure Measurement 16bar | ||
Minimum Pressure Measurement 0bar | ||
Accuracy ±1 to ±2.4 % rdg | ||
Series A-10 | ||
Standards/Approvals No | ||
Housing Material 316L Stainless Steel | ||
Maximum Operating Temperature 80°C | ||
Minimum Operating Temperature 0°C | ||
IP Rating IP65 | ||
- COO (Country of Origin):
- DE
The WIKAs field-proven model A-10 pressure transmitter (pressure sensor) is the all-rounder for pressure measurement in industrial environments. Compactly built, it can be integrated into a wide range of machine designs. The many measuring ranges, and special measuring ranges, contribute to its universal applicability.
Excellent quality and proven technology
Exceptionally large variety covers almost all applications
All configurable variants are available at short notice from quantities of 1 upwards
Particularly cost-efficient
