Honeywell Pressure Sensor, 125psi Max, Regulated Output, Relative Reading
- RS Stock No.:
- 213-2740
- Mfr. Part No.:
- MLH125PGL01C
- Brand:
- Honeywell
Available to back order for despatch 19/06/2024
Added
Price Each
£205.21
(exc. VAT)
£246.25
(inc. VAT)
| Units | Per unit |
| 1 + | £205.21 |
- RS Stock No.:
- 213-2740
- Mfr. Part No.:
- MLH125PGL01C
- Brand:
- Honeywell
Technical Reference
Legislation and Compliance
RoHS Status: Not Applicable
Product Details
The Honeywell MLH series heavy duty pressure transducers combine application specific integrated circuit (ASIC) technology with a media-isolated, metal diaphragm design. It has 125 psi pressure range.
Total Error Band (TEB) as low as 2 %FSS
Compensated and operating temperature range of -40°C to 125°C
Less than 2 ms response time
Fully temperature compensated, calibrated and amplified
Rated IP65 or better for protection from most harsh environments
Compensated and operating temperature range of -40°C to 125°C
Less than 2 ms response time
Fully temperature compensated, calibrated and amplified
Rated IP65 or better for protection from most harsh environments
Specifications
Attribute | Value |
|---|---|
| Pressure Reading Type | Relative |
| Maximum Pressure Reading | 125psi |
| Accuracy | ±0.25% |
| Output Type | Regulated |
| Media Measured | Gas, Liquid, Oil |
| Supply Voltage | 24 V |
| IP Rating | IP65 |
