WIKA S-11 Series Pressure Sensor, 0bar Min, 600bar Max, Current Output
- RS Stock No.:
- 190-9722
- Mfr. Part No.:
- 9023585
- Brand:
- WIKA
Subtotal (1 unit)*
£428.19
(exc. VAT)
£513.83
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 28 November 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £428.19 |
*price indicative
- RS Stock No.:
- 190-9722
- Mfr. Part No.:
- 9023585
- Brand:
- WIKA
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | WIKA | |
| Minimum Pressure Reading | 0bar | |
| Maximum Pressure Reading | 600bar | |
| Accuracy | ±0.5 % | |
| Output Type | Current | |
| Media Measured | Adhesive, Contaminated Media, Crystallising, Particle-Laden, Paste-Like, Viscous | |
| Process Connection | G1/2 | |
| Electrical Connection | Angular connector DIN 175301-803 A | |
| Analogue Output | 4 → 20 mA | |
| Series | S-11 | |
| Maximum Current | 20 mA | |
| Supply Voltage | 10 → 30 V dc | |
| Housing Material | Stainless Steel | |
| Mounting Type | Thread Mount | |
| IP Rating | IP65 | |
| Maximum Operating Temperature | +100°C | |
| Minimum Operating Temperature | -30°C | |
Select all | ||
|---|---|---|
Brand WIKA | ||
Minimum Pressure Reading 0bar | ||
Maximum Pressure Reading 600bar | ||
Accuracy ±0.5 % | ||
Output Type Current | ||
Media Measured Adhesive, Contaminated Media, Crystallising, Particle-Laden, Paste-Like, Viscous | ||
Process Connection G1/2 | ||
Electrical Connection Angular connector DIN 175301-803 A | ||
Analogue Output 4 → 20 mA | ||
Series S-11 | ||
Maximum Current 20 mA | ||
Supply Voltage 10 → 30 V dc | ||
Housing Material Stainless Steel | ||
Mounting Type Thread Mount | ||
IP Rating IP65 | ||
Maximum Operating Temperature +100°C | ||
Minimum Operating Temperature -30°C | ||
