Telemecanique Sensors Pressure Switch, -1bar Min, 1bar Max, Analogue Output, Differential Reading
- RS Stock No.:
- 146-2943
- Mfr. Part No.:
- XMLPM01GD71F
- Brand:
- Telemecanique Sensors
Discontinued
Alternative
This product is not currently available. Here is our alternative recommendation.
Each
£169.07
(exc. VAT)
£202.88
(inc. VAT)
- RS Stock No.:
- 146-2943
- Mfr. Part No.:
- XMLPM01GD71F
- Brand:
- Telemecanique Sensors
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Telemecanique Sensors | |
| Pressure Reading Type | Differential | |
| Minimum Pressure Reading | -1bar | |
| Maximum Pressure Reading | 1bar | |
| Accuracy | 0.1 % | |
| Output Type | Analogue | |
| Media Measured | Air, Fresh Water, Gas, Hydraulic Oil | |
| Electrical Connection | 4-Pin M12 Male Connector | |
| Analogue Output | 0 → 10 V | |
| Response Time | ≤2 ms | |
| Maximum Current | <7 mA | |
| Supply Voltage | 24 V dc | |
| Housing Material | Ceramic, FPM, Stainless Steel 316L | |
| Mounting Type | Cable Mount | |
| Minimum Operating Temperature | -30°C | |
| IP Rating | IP65, IP67, IP69K | |
| Maximum Operating Temperature | +85°C | |
| Select all | ||
|---|---|---|
Brand Telemecanique Sensors | ||
Pressure Reading Type Differential | ||
Minimum Pressure Reading -1bar | ||
Maximum Pressure Reading 1bar | ||
Accuracy 0.1 % | ||
Output Type Analogue | ||
Media Measured Air, Fresh Water, Gas, Hydraulic Oil | ||
Electrical Connection 4-Pin M12 Male Connector | ||
Analogue Output 0 → 10 V | ||
Response Time ≤2 ms | ||
Maximum Current <7 mA | ||
Supply Voltage 24 V dc | ||
Housing Material Ceramic, FPM, Stainless Steel 316L | ||
Mounting Type Cable Mount | ||
Minimum Operating Temperature -30°C | ||
IP Rating IP65, IP67, IP69K | ||
Maximum Operating Temperature +85°C | ||
Adjustable electromechanical pressure switches from basic pressure transmitters to configurable pressure switches for pumping, hydraulic, and HVAC machinery
Electronic pressure sensors
OsiSense XM
XMLP pressure transmitters
Compact metal body, 316L stainless steel fluid entry
With analogue output. Sizes in bar
OsiSense XM
XMLP pressure transmitters
Compact metal body, 316L stainless steel fluid entry
With analogue output. Sizes in bar
Adjustable electromechanical pressure switches, in which we are a recognized leader in industrial applications Electronic pressure sensors and switches with a full range from basic pressure transmitters to configurable pressure switches for pumping, hydraulic, and HVAC machinery
