Telemecanique Sensors Pressure Switch, 0bar Min, 10bar Max, Analogue Output
- RS Stock No.:
- 135-3763
- Mfr. Part No.:
- XMLK010B2C21
- Brand:
- Telemecanique Sensors
Subtotal (1 unit)*
£184.63
(exc. VAT)
£221.56
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 1 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £184.63 |
*price indicative
- RS Stock No.:
- 135-3763
- Mfr. Part No.:
- XMLK010B2C21
- Brand:
- Telemecanique Sensors
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Telemecanique Sensors | |
| Minimum Pressure Reading | 0bar | |
| Maximum Pressure Reading | 10bar | |
| Accuracy | ±0.3 % | |
| Output Type | Analogue | |
| Media Measured | Air, Fresh Water | |
| Analogue Output | 4 → 20 mA | |
| Electrical Connection | DIN 43650A 4-Pin Male Connector | |
| Response Time | 2 ms | |
| Maximum Current | 20 mA | |
| Supply Voltage | 24 V dc | |
| Housing Material | Stainless Steel | |
| Minimum Operating Temperature | 0°C | |
| IP Rating | IP65 | |
| Mounting Type | Plug-In Mount | |
| Maximum Operating Temperature | +80°C | |
Select all | ||
|---|---|---|
Brand Telemecanique Sensors | ||
Minimum Pressure Reading 0bar | ||
Maximum Pressure Reading 10bar | ||
Accuracy ±0.3 % | ||
Output Type Analogue | ||
Media Measured Air, Fresh Water | ||
Analogue Output 4 → 20 mA | ||
Electrical Connection DIN 43650A 4-Pin Male Connector | ||
Response Time 2 ms | ||
Maximum Current 20 mA | ||
Supply Voltage 24 V dc | ||
Housing Material Stainless Steel | ||
Minimum Operating Temperature 0°C | ||
IP Rating IP65 | ||
Mounting Type Plug-In Mount | ||
Maximum Operating Temperature +80°C | ||
- COO (Country of Origin):
- CH
OsiSense XMLK Pressure Sensors
Schneider Electric XMLK pressure transmitters are feature a ceramic pressure measuring cell and are available with various types of electrical connector and fluid connections. Deformation, caused by pressure, changes the resistance of the resistors of a Wheatstone bridge silk-screened on the ceramic. The change in resistance is then processed by the integrated electronics to provide an analogue output signal.
