Hongfa Europe GMBH PCB Mount Latching Power Relay, 24V dc Coil, 10A Switching Current, SPST

RS Stock No.:: 176-2845
Mfr. Part No.:: HF163F-L/24-HL1T
Brand:: Hongfa Europe GMBH

Hongfa Europe GMBH PCB Mount Latching Power Relay, 24V dc Coil, 10A Switching Current, SPST

106 In stock - FREE next working day delivery available

Added

Price Each (In a Pack of 2)

£2.535

(exc. VAT)

£3.042

(inc. VAT)

Units	Per unit	Per Pack*
2 +	£2.535	£5.07
*price indicative

RS Stock No.:: 176-2845
Mfr. Part No.:: HF163F-L/24-HL1T
Brand:: Hongfa Europe GMBH

Technical Reference

Datasheet

Legislation and Compliance

COO (Country of Origin):: CN

Product Details

Latching relay
High sensitive
Breakdown voltage (between contact and coil): 5,000 V
High switching capacity: 8A 250VAC
Surge breakdown voltage (between contact and coil): 12,000 V
Reflow soldering available
1 Form A configuration
Environmental friendly product
Outline Dimensions: (24.0 x 10.0 x 18.8) mm

Specifications

Attribute	Value
Coil Voltage	24V dc
Contact Configuration	SPST
Mounting Type	PCB Mount
Switching Current	10A
Number of Poles	1
Latching	Yes
Terminal Type	PCB Pin
Maximum Switching Voltage AC	250V
Maximum Switching Voltage DC	30V dc
Maximum Switching Current AC	10 A
Maximum Switching Current DC	10 A
Length	24mm
Coil Resistance	2880Ω
Coil Power	200mW
Height	18.8mm
Contact Material	Silver Alloy
Standards Met	cULus File No:E134517, VDE File No:40039460
Depth	10mm
Life	1 x 10^6 cycles
Series	HF163F-L
Minimum Operating Temperature	-40°C
Maximum Operating Temperature	+85°C
Isolation Coil To Contact	5kV ac
Maximum Switching Power AC	2.5 kVA
Maximum Switching Power DC	150 W
Dimensions	24 x 10 x 18.8mm
