RS PRO NYM-J 6 mm² 5 Core Power Cable, Grey PVC, 100m
- RS Stock No.:
- 902-8366
- Brand:
- RS PRO
Unavailable
RS will no longer stock this product.
- RS Stock No.:
- 902-8366
- Brand:
- RS PRO
Specifications
Technical Reference
Legislation and Compliance
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | RS PRO | |
| Cross Sectional Area | 6 mm² | |
| Number of Cores | 5 | |
| Sheath Colour | Grey | |
| Length | 100m | |
| Cable Type | NYM-J | |
| CPR Certification | Eca | |
| Sheath Material | PVC | |
| Outer Diameter | 15 → 17.5mm | |
| Voltage Rating | 300 V, 500 V | |
| Conductor Strand Type | Solid | |
| Fire Behaviour | Flame Retardant | |
| Maximum Operating Temperature | +70°C | |
| Conductor Resistance | 3.08 Ω/km | |
| Minimum Operating Temperature | -5°C | |
| Standards Met | HD 21.4 S2, IEC 60288, IEC 60332-1 | |
| Insulation Material | PVC | |
| Size of Strands | 2.69 mm | |
| Select all | ||
|---|---|---|
Brand RS PRO | ||
Cross Sectional Area 6 mm² | ||
Number of Cores 5 | ||
Sheath Colour Grey | ||
Length 100m | ||
Cable Type NYM-J | ||
CPR Certification Eca | ||
Sheath Material PVC | ||
Outer Diameter 15 → 17.5mm | ||
Voltage Rating 300 V, 500 V | ||
Conductor Strand Type Solid | ||
Fire Behaviour Flame Retardant | ||
Maximum Operating Temperature +70°C | ||
Conductor Resistance 3.08 Ω/km | ||
Minimum Operating Temperature -5°C | ||
Standards Met HD 21.4 S2, IEC 60288, IEC 60332-1 | ||
Insulation Material PVC | ||
Size of Strands 2.69 mm | ||
- COO (Country of Origin):
- TR
