RS PRO 1.5 mm² 2 Core Power Cable, Brown/Red Silicone, 50m
- RS Stock No.:
- 136-8186
- Brand:
- RS PRO
Currently unavailable
We don’t know if this item will be back in stock, it is being discontinued by the manufacturer.
Alternative
This product is not currently available. Here is our alternative recommendation.
1 Reel of 50 Metre(s)
£135.11
(exc. VAT)
£162.13
(inc. VAT)
- RS Stock No.:
- 136-8186
- Brand:
- RS PRO
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | RS PRO | |
| Cross Sectional Area | 1.5 mm² | |
| Number of Cores | 2 | |
| Sheath Colour | Brown/Red | |
| Length | 50m | |
| Sheath Material | Silicone | |
| Outer Diameter | 7.4mm | |
| Voltage Rating | 300 V, 500 V | |
| Conductor Strand Type | Stranded | |
| Standards Met | IEC 60228, IEC 60228, Class 5, IEC 60754-1 Halogen-Free, NF C 32-070/C2 or IEC 60332-1 Flame Retardant | |
| Cable Shape | Multicore | |
| Minimum Operating Temperature | -60°C | |
| Series | SIHF | |
| American Wire Gauge | 15 AWG | |
| Fire Behaviour | Flame Retardant | |
| Maximum Operating Temperature | +180°C | |
| Conductor Material | Copper | |
Select all | ||
|---|---|---|
Brand RS PRO | ||
Cross Sectional Area 1.5 mm² | ||
Number of Cores 2 | ||
Sheath Colour Brown/Red | ||
Length 50m | ||
Sheath Material Silicone | ||
Outer Diameter 7.4mm | ||
Voltage Rating 300 V, 500 V | ||
Conductor Strand Type Stranded | ||
Standards Met IEC 60228, IEC 60228, Class 5, IEC 60754-1 Halogen-Free, NF C 32-070/C2 or IEC 60332-1 Flame Retardant | ||
Cable Shape Multicore | ||
Minimum Operating Temperature -60°C | ||
Series SIHF | ||
American Wire Gauge 15 AWG | ||
Fire Behaviour Flame Retardant | ||
Maximum Operating Temperature +180°C | ||
Conductor Material Copper | ||
- COO (Country of Origin):
- TR
RS PRO 2-Core 1.5 mm² High-Temperature Cable, Red-Brown Silicone Sheath 50 m, 300 V, 500 V
Use these high-temperature cables from the RS PRO range when you need to install wiring in harsh environments. They're designed with a variety of safety features that ensure they're suitable for use in temperatures ranging from -60°C to +180°C.
These cables have an outer sheath made from a silicone elastomer material. This increases the safety of the cable by insulating the electric current effectively. The sheath is also resistant to mechanical damage, corrosion and chemicals, making these wires a long-lasting product.
These cables are flame-retardant to ensure a reduced risk of fire. They also won't release toxic fumes into the air in the event of a fire, as they're halogen-free.
These cables have an outer sheath made from a silicone elastomer material. This increases the safety of the cable by insulating the electric current effectively. The sheath is also resistant to mechanical damage, corrosion and chemicals, making these wires a long-lasting product.
These cables are flame-retardant to ensure a reduced risk of fire. They also won't release toxic fumes into the air in the event of a fire, as they're halogen-free.
Features and Benefits
- American wire gauge of 15 AWG
- Copper conductor material
- Stranded conductor type
- Cross-sectional area of 1.5 mm²
- Flame-retardant
- Length of 50 m
- Operating temperature range of -60°C to +180°C
- Two cores
- Outer diameter of 7.4 mm
- SIHF (silicone sheath, halogen-free) series
- Red-brown sheath colour
- Silicone sheath material
- Meets IEC 60228, IEC 60228, Class 5, IEC 60754-1 Halogen-Free, NF C 32-070/C2 or IEC 60332-1 fire safety standards
- Voltage rating of 300 V, 500 V
