RS PRO 4 mm² 3 Core Mains Power Cable Thermoplastic Elastomers TPE, 100m
- RS Stock No.:
- 535-975
- Brand:
- RS PRO
Unavailable
RS will no longer stock this product.
Alternative
This product is not currently available. Here is our alternative recommendation.
1 Reel of 100 Metre(s)
£884.42
(exc. VAT)
£1,061.30
(inc. VAT)
- RS Stock No.:
- 535-975
- Brand:
- RS PRO
Specifications
Technical Reference
Legislation and Compliance
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | RS PRO | |
| Cross Sectional Area | 4 mm² | |
| Number of Cores | 3 | |
| Length | 100m | |
| Current Rating | 40 A | |
| Outer Diameter | 16.2mm | |
| Sheath Material | Thermoplastic Elastomers TPE | |
| Voltage Rating | 450/750 V | |
| Conductor Strand Type | Stranded | |
| Standards Met | HD 22.4, IEC 245-4, NFC 32-102, RoHS Compliant | |
| Maximum Operating Temperature | +85°C | |
| Conductor Material | Copper | |
| American Wire Gauge | 11 AWG | |
| Minimum Operating Temperature | -25°C | |
| Insulation Material | Rubber Compound | |
| Select all | ||
|---|---|---|
Brand RS PRO | ||
Cross Sectional Area 4 mm² | ||
Number of Cores 3 | ||
Length 100m | ||
Current Rating 40 A | ||
Outer Diameter 16.2mm | ||
Sheath Material Thermoplastic Elastomers TPE | ||
Voltage Rating 450/750 V | ||
Conductor Strand Type Stranded | ||
Standards Met HD 22.4, IEC 245-4, NFC 32-102, RoHS Compliant | ||
Maximum Operating Temperature +85°C | ||
Conductor Material Copper | ||
American Wire Gauge 11 AWG | ||
Minimum Operating Temperature -25°C | ||
Insulation Material Rubber Compound | ||
- COO (Country of Origin):
- IT
