SMC Quick Exhaust Valve, R 1/4 Male x 1 MPa, Threaded, Tube, 8mm
- RS Stock No.:
- 209-9226
- Distrelec Article No.:
- 303-97-119
- Mfr. Part No.:
- ASV410F-02-08S
- Brand:
- SMC
Save 9% when you buy 10 units
Subtotal (1 unit)*
£24.22
(exc. VAT)
£29.06
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 140 unit(s) ready to ship
- Plus 27 unit(s) ready to ship from another location
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 - 4 | £24.22 |
| 5 - 9 | £22.78 |
| 10 + | £21.85 |
*price indicative
- RS Stock No.:
- 209-9226
- Distrelec Article No.:
- 303-97-119
- Mfr. Part No.:
- ASV410F-02-08S
- Brand:
- SMC
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | SMC | |
| Threaded Connections | R 1/4 Male | |
| Tube Connections | 8mm | |
| Connection Type | Threaded, Tube | |
| Maximum Operating Pressure | 1 MPa | |
| Manufacturer Series | ASV | |
| Built-In Silencer | Yes | |
| Threaded Connection - Gender | Male | |
| Threaded Connection Size | 1/4in | |
| Minimum Operating Pressure | 0.1MPa | |
| Threaded Connection Type | R | |
Select all | ||
|---|---|---|
Brand SMC | ||
Threaded Connections R 1/4 Male | ||
Tube Connections 8mm | ||
Connection Type Threaded, Tube | ||
Maximum Operating Pressure 1 MPa | ||
Manufacturer Series ASV | ||
Built-In Silencer Yes | ||
Threaded Connection - Gender Male | ||
Threaded Connection Size 1/4in | ||
Minimum Operating Pressure 0.1MPa | ||
Threaded Connection Type R | ||
RoHS Status: Exempt
- COO (Country of Origin):
- JP
SMC ASV Series Quick Exhaust Valve, 1/4 in Threaded Connection size, 8mm Tube Connection - ASV410F-02-08S
This quick exhaust valve is a crucial component in pneumatic systems, designed to efficiently control airflow and reduce cycle times. Featuring a compact and durable construction with a body made from PBT, this valve is ideal for various industrial applications. It includes a threaded R 1/4 male connection and accommodates 8mm tube connections, ensuring seamless integration into existing setups.
Features & Benefits
• Built-in silencer reduces noise levels during operation
• Capable of operating at a maximum pressure of 1 MPa
• Minimum operating pressure as low as 0.1 MPa for flexibility
• Quick exhaust enables faster cylinder response times
• Flame-resistant resin body enhances safety standards
• Corrosion-resistant electroless nickel plating on brass parts
• Capable of operating at a maximum pressure of 1 MPa
• Minimum operating pressure as low as 0.1 MPa for flexibility
• Quick exhaust enables faster cylinder response times
• Flame-resistant resin body enhances safety standards
• Corrosion-resistant electroless nickel plating on brass parts
Applications
• Used in automation systems for improved cylinder timing
• Employed in pneumatic machinery for efficient airflow control
• Utilised in robotics for precise movement regulation
• Integrated into air-powered tools for enhanced performance
• Employed in pneumatic machinery for efficient airflow control
• Utilised in robotics for precise movement regulation
• Integrated into air-powered tools for enhanced performance
How does the built-in silencer improve operational efficiency?
The built-in silencer significantly decreases noise generated by exhaust airflow, which makes the work environment more comfortable while allowing for discreet operation in sensitive areas.
What materials are compatible with the valve for optimal performance?
This valve is recommended for use with nylon, soft nylon, and polyurethane tubing, which align with its pressure specifications and enhance overall functionality.
What impact does the body material have on durability in harsh conditions?
The PBT construction ensures excellent resistance to various environmental factors, making it suitable for demanding applications while maintaining structural integrity over time.
How does the valve operate under varying pressure conditions?
It operates efficiently between a minimum pressure of 0.1 MPa and a maximum of 1 MPa, allowing it to adapt to different system requirements effectively while maintaining performance consistency.
What are the benefits of using a pneumatic quick exhaust valve compared to standard valves?
A pneumatic quick exhaust valve allows for rapid airflow release, significantly improving cycle times and efficiency in applications requiring fast actuation, minimising downtime in production processes.
