SMC Pressure Sensor, IP40 1.5 Mpa 24V dc 50 °C
- RS Stock No.:
- 844-4650
- Mfr. Part No.:
- PSE530-M5
- Brand:
- SMC
Bulk discount available
Subtotal (1 unit)*
£50.83
(exc. VAT)
£61.00
(inc. VAT)
FREE delivery for orders over £60.00
In Stock
- 20 unit(s) ready to ship
- Plus 16 unit(s) ready to ship from another location
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 - 4 | £50.83 |
| 5 + | £48.79 |
*price indicative
- RS Stock No.:
- 844-4650
- Mfr. Part No.:
- PSE530-M5
- Brand:
- SMC
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | SMC | |
| Suitable Medias | Air, Gas, Non-Corrosive Gas | |
| Product Type | Pressure Sensor | |
| Minimum Operating Pressure | 0MPa | |
| Connection Thread Standard | Metric | |
| Pressure Type | Positive Pressure | |
| Port Size | M5 x 0.8 | |
| Voltage | 24V dc | |
| IP Rating | IP40 | |
| Maximum Operating Temperature | 50°C | |
| Maximum Operating Pressure | 1.5 Mpa | |
| Minimum Operating Temperature | 0°C | |
| Port Gender | Male | |
| Height | 29.4mm | |
| Width | 12mm | |
| Series | PSE530 | |
| Standards/Approvals | RoHS, CE | |
| Select all | ||
|---|---|---|
Brand SMC | ||
Suitable Medias Air, Gas, Non-Corrosive Gas | ||
Product Type Pressure Sensor | ||
Minimum Operating Pressure 0MPa | ||
Connection Thread Standard Metric | ||
Pressure Type Positive Pressure | ||
Port Size M5 x 0.8 | ||
Voltage 24V dc | ||
IP Rating IP40 | ||
Maximum Operating Temperature 50°C | ||
Maximum Operating Pressure 1.5 Mpa | ||
Minimum Operating Temperature 0°C | ||
Port Gender Male | ||
Height 29.4mm | ||
Width 12mm | ||
Series PSE530 | ||
Standards/Approvals RoHS, CE | ||
- COO (Country of Origin):
- JP
Compact Pneumatic Pressure Sensor
Series PSE digital pressure switches allow pressure to be controlled from a remote location. The PSE100 series controller has an easy to read, large, 4-digit LED display. Display units can be easily selected and changed. Series PSE510 is compact and lightweight, allowing the sensor to be mounted where needed. The use of stainless steel for all wetted parts (SUS630 for diaphragm, SUS304 for fitting) allows the PSE520 pressure sensor to be used in a wide variety of gas and fluid applications.
PSE series remote pressure and vacuum sensors have been expanded to include easy-to-use econ connectors from 3M or AMP.
