SMC Pneumatic Piston Rod Cylinder - 6mm Bore, 5mm Stroke, CJP Series, Single Acting
- RS Stock No.:
- 183-3946
- Mfr. Part No.:
- CJPB6-5H6
- Brand:
- SMC
Bulk discount available
Subtotal (1 unit)*
£17.24
(exc. VAT)
£20.69
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 1 unit(s) ready to ship
- Plus 14 unit(s) ready to ship from another location
- Plus 3 unit(s) shipping from 16 October 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 - 4 | £17.24 |
| 5 - 9 | £16.23 |
| 10 + | £15.55 |
*price indicative
Alternative
This product is not currently available. Here is our alternative recommendation.
Each
£17.24
(exc. VAT)
£20.69
(inc. VAT)
- RS Stock No.:
- 183-3946
- Mfr. Part No.:
- CJPB6-5H6
- Brand:
- SMC
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | SMC | |
| Manufacturer Series | CJP | |
| Bore | 6mm | |
| Action | Single | |
| Stroke | 5mm | |
| Port Connection | M5 x 0.8 | |
| Cushioning Type | Not Cushioned | |
| Dimensions | 27.5 x 12 x 13.9mm | |
| Length | 27.5mm | |
| Height | 13.9mm | |
| Width | 12mm | |
| Maximum Operating Pressure | 0.7 MPa | |
| Weight | 10.6g | |
| Maximum Operating Temperature | +70°C | |
| Piston Speed | 50 → 500mm/s | |
| Minimum Operating Temperature | -10°C | |
Select all | ||
|---|---|---|
Brand SMC | ||
Manufacturer Series CJP | ||
Bore 6mm | ||
Action Single | ||
Stroke 5mm | ||
Port Connection M5 x 0.8 | ||
Cushioning Type Not Cushioned | ||
Dimensions 27.5 x 12 x 13.9mm | ||
Length 27.5mm | ||
Height 13.9mm | ||
Width 12mm | ||
Maximum Operating Pressure 0.7 MPa | ||
Weight 10.6g | ||
Maximum Operating Temperature +70°C | ||
Piston Speed 50 → 500mm/s | ||
Minimum Operating Temperature -10°C | ||
RoHS Status: Exempt
- COO (Country of Origin):
- JP
SMC CJP
Miniature pin cylinders for panel mount. All cylinders are single acting with spring return.
Lubrication not required
Threaded rod-end style
Non-cushioned
Proof pressure 10.5 bar
Operating pressure 2 bar, 6mm dia and 1.5 bar, 10mm/15mm dia (min) 7 bar (max)
Ambient and fluid temperature 5°C to 60°C
Stroke tolerance: +1.0mm
Threaded rod-end style
Non-cushioned
Proof pressure 10.5 bar
Operating pressure 2 bar, 6mm dia and 1.5 bar, 10mm/15mm dia (min) 7 bar (max)
Ambient and fluid temperature 5°C to 60°C
Stroke tolerance: +1.0mm
Note
Outward Thrust and Return Thrust or Pull are calculated at maximum operating pressure (7bar).
