SMC 4 Finger Double Acting Action Pneumatic Gripper, MHS4-16D, Parallel Gripping Type
- RS Stock No.:
- 393-248
- Mfr. Part No.:
- MHS4-16D
- Brand:
- SMC
Subtotal (1 unit)*
£489.21
(exc. VAT)
£587.05
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 30 March 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £489.21 |
*price indicative
- RS Stock No.:
- 393-248
- Mfr. Part No.:
- MHS4-16D
- Brand:
- SMC
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | SMC | |
| Bore Size | 16 mm | |
| Number of Fingers | 4 | |
| Product Type | Pneumatic Gripper | |
| Gripping Type | Parallel | |
| Action Type | Double Acting | |
| Series | MHS4 | |
| Maximum Operating Pressure | 7 bar | |
| Weight | 0.066kg | |
| Gripping Force - Internal | 12N | |
| Gripping Force - External | 10N | |
| Minimum Operating Temperature | -10°C | |
| Maximum Operating Temperature | 60°C | |
| Standards/Approvals | IEC 60204-1, ISO 10218-1, RoHS, ISO 4413, ISO 4414 | |
| Width | 30 mm | |
| Length | 30mm | |
| Height | 35mm | |
| Maximum Operating Frequency | 120cpm | |
| Select all | ||
|---|---|---|
Brand SMC | ||
Bore Size 16 mm | ||
Number of Fingers 4 | ||
Product Type Pneumatic Gripper | ||
Gripping Type Parallel | ||
Action Type Double Acting | ||
Series MHS4 | ||
Maximum Operating Pressure 7 bar | ||
Weight 0.066kg | ||
Gripping Force - Internal 12N | ||
Gripping Force - External 10N | ||
Minimum Operating Temperature -10°C | ||
Maximum Operating Temperature 60°C | ||
Standards/Approvals IEC 60204-1, ISO 10218-1, RoHS, ISO 4413, ISO 4414 | ||
Width 30 mm | ||
Length 30mm | ||
Height 35mm | ||
Maximum Operating Frequency 120cpm | ||
- COO (Country of Origin):
- JP
The SMC Air Gripper designed for precise handling of square and round workpieces. Its compact wedge cam design ensures high holding force, making it ideal for space-constrained pick-and-place applications.
Suitable for both square and round workpieces
Durable construction for reliable performance
Ideal for end-of-arm tooling in limited spaces
