Weidmüller OMNIMATE Signal Series PCB Connector, 3-Contact, 2.5 mm Pitch, PCB, 1 Row Solder
- RS Stock No.:
- 255-8314
- Mfr. Part No.:
- 2439760000
- Brand:
- Weidmüller
Subtotal (1 box of 250 units)*
£150.46
(exc. VAT)
£180.55
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 22 July 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Box(es) | Per Box | Per unit* |
|---|---|---|
| 1 + | £150.46 | £0.602 |
*price indicative
- RS Stock No.:
- 255-8314
- Mfr. Part No.:
- 2439760000
- Brand:
- Weidmüller
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Weidmüller | |
| Product Type | PCB Connector | |
| Number of Contacts | 3 | |
| Pitch | 2.5mm | |
| Number of Rows | 1 | |
| Current | 6A | |
| Housing Material | Polyamide 66 | |
| Mount Type | PCB | |
| Connector Gender | Male | |
| Orientation | 90° | |
| Termination Type | Solder | |
| Colour | Black | |
| Voltage | 32 V | |
| Contact Gender | Male | |
| Standards/Approvals | DIN VDE 0627, IEC 61984, IPC-A-610 \Class 2 | |
| Width | 9.4 mm | |
| Length | 5mm | |
| Series | OMNIMATE Signal | |
| Depth | 10.1mm | |
| Select all | ||
|---|---|---|
Brand Weidmüller | ||
Product Type PCB Connector | ||
Number of Contacts 3 | ||
Pitch 2.5mm | ||
Number of Rows 1 | ||
Current 6A | ||
Housing Material Polyamide 66 | ||
Mount Type PCB | ||
Connector Gender Male | ||
Orientation 90° | ||
Termination Type Solder | ||
Colour Black | ||
Voltage 32 V | ||
Contact Gender Male | ||
Standards/Approvals DIN VDE 0627, IEC 61984, IPC-A-610 \Class 2 | ||
Width 9.4 mm | ||
Length 5mm | ||
Series OMNIMATE Signal | ||
Depth 10.1mm | ||
- COO (Country of Origin):
- DE
The Weidmuller PCB plug-in connector has male header for wave soldering in 2.50 mm pitch and THT solder connection mounting with three poles.
Plugging direction is parallel 90 degree to the PCB
Closed housing variant
Packaged in a cardboard box (BX)
