Phoenix Contact, 7.62mm Pitch, DFK, 7 Way, , Pluggable Terminal Block, Feed Through Plug, Screw, Screw Termination,
- RS Stock No.:
- 499-387
- Mfr. Part No.:
- 1716551
- Brand:
- Phoenix Contact
Subtotal (1 pack of 10 units)*
£1,237.89
(exc. VAT)
£1,485.47
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 12 January 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Pack(s) | Per Pack | Per unit* |
---|---|---|
1 + | £1,237.89 | £123.789 |
*price indicative
- RS Stock No.:
- 499-387
- Mfr. Part No.:
- 1716551
- Brand:
- Phoenix Contact
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | Phoenix Contact | |
Pluggable Terminal Block Type | Feed Through Plug | |
Number of Contacts | 7 | |
Pitch | 7.62mm | |
Series | DFK | |
Number of Rows | 1 | |
Body Orientation | Straight | |
Mounting Type | Screw | |
Termination Method | Screw | |
Select all | ||
---|---|---|
Brand Phoenix Contact | ||
Pluggable Terminal Block Type Feed Through Plug | ||
Number of Contacts 7 | ||
Pitch 7.62mm | ||
Series DFK | ||
Number of Rows 1 | ||
Body Orientation Straight | ||
Mounting Type Screw | ||
Termination Method Screw | ||
- COO (Country of Origin):
- PL
The Phoenix Contact Feed-through plug offers a reliable connection solution tailored for various applications, ensuring optimal performance. Featuring advanced engineering, it supports a nominal cross-section of 6 mm² and a current rating of 32 A, making it ideal for demanding environments. Its robust design incorporates an innovative screw connection with a tension sleeve, allowing easy and secure wire attachment. The product ensures minimal temperature rise during operation due to its effective contact force mechanism, providing enhanced reliability and longevity. This feed-through connector is part of the well-regarded DFK-PC series, designed with the versatility to cater to multiple industrial needs, from automation to control systems.
Allows connection of two conductors efficiently
Designed for tool-free snap-in locking, ensuring quick installation
Constructed from high-quality materials to support long-lasting usage
Offers excellent contact resistance to enhance electrical conductivity
Features an insulating material rated for high thermal performance
Provides a compact footprint of 78.84 mm width, fitting into tight spaces
Designed for tool-free snap-in locking, ensuring quick installation
Constructed from high-quality materials to support long-lasting usage
Offers excellent contact resistance to enhance electrical conductivity
Features an insulating material rated for high thermal performance
Provides a compact footprint of 78.84 mm width, fitting into tight spaces
