Phoenix Contact SMKDS 3/ 5-5.08 Series PCB Terminal Block, 5-Contact, 5.08mm Pitch, Through Hole Mount, Screw
- RS Stock No.:
- 883-3031
- Mfr. Part No.:
- 1713309
- Brand:
- Phoenix Contact
Available to back order for despatch 01/07/2024
Price Each (In a Box of 50)
£1.993
(exc. VAT)
£2.392
(inc. VAT)
| Units | Per unit | Per Box* |
| 50 + | £1.993 | £99.65 |
| *price indicative | ||
- RS Stock No.:
- 883-3031
- Mfr. Part No.:
- 1713309
- Brand:
- Phoenix Contact
Technical Reference
Legislation and Compliance
- COO (Country of Origin):
- DE
Product Details
PCB terminal block, nominal current: 24 A, rated voltage (III/2): 400 V, nominal cross section: 2.5 mm², Number of potentials: 5, Number of rows: 1, Number of positions per row: 5, product range: SMKDS 3, pitch: 5.08 mm, connection method: Screw connection with tension sleeve, mounting: Wave soldering, conductor/PCB connection direction: 55 °, color: green, Pin layout: Linear pinning, Solder pin [P]: 4.5 mm, type of packaging: packed in cardboard. The article can be aligned to create different nos. of positions!
Specifications
Attribute | Value |
|---|---|
| Number of Contacts | 5 |
| Pitch | 5.08mm |
| Mounting Type | Through Hole |
| Termination Method | Screw |
| Type | PCB Terminal Block |
| Current Rating | 24A |
| Colour | Green |
| Voltage Rating | 630 V |
| Series | SMKDS 3/ 5-5.08 |
| Material | Polyamide |
| Length | 16mm |
