Phoenix Contact KDSP 1.5/ 2 Series PCB Terminal Block, 2-Contact, 5mm Pitch, Through Hole Mount, Screw Termination

View all PCB Terminal Blocks

Subtotal (1 box of 50 units)*

£218.70

(exc. VAT)

£262.45

(inc. VAT)

Add to Basket
Select or type quantity
Temporarily out of stock
  • Shipping from 17 December 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units
Per unit
Per Box*
50 +£4.374£218.70

*price indicative

RS Stock No.:
882-5428
Mfr. Part No.:
1780905
Brand:
Phoenix Contact
Find similar products by selecting one or more attributes.
Select all

Brand

Phoenix Contact

Number of Contacts

2

Pitch

5mm

Mounting Type

Through Hole

Termination Method

Screw

Type

PCB Terminal Block

Current Rating

17.5A

Colour

Green

Voltage Rating

630 V

Series

KDSP 1.5/ 2

Length

18.8mm

Material

Polyamide

COO (Country of Origin):
PL
PCB terminal block, nominal current: 17.5 A, rated voltage (III/2): 400 V, nominal cross section: 1.5 mm², Number of potentials: 2, Number of rows: 1, Number of positions per row: 2, product range: KDSP 1,5, pitch: 5 mm, connection method: Screw connection with tension sleeve, mounting: Wave soldering, conductor/PCB connection direction: 0 °, color: green, Pin layout: Linear pinning, Solder pin [P]: 3.7 mm, type of packaging: packed in cardboard. The article can be aligned to create different nos. of positions!
