Phoenix Contact PC Series PCB Header, 2-Contact, 7.62mm Pitch, Through Hole Mount, 1-Row, Solder Termination

View all PCB Terminal Blocks
Currently unavailable
We don’t know if this item will be back in stock, it is being discontinued by the manufacturer.
RS Stock No.:
803-0683
Mfr. Part No.:
1720466
Brand:
Phoenix Contact
Find similar products by selecting one or more attributes.
Select all

Brand

Phoenix Contact

Number of Contacts

2

Pitch

7.62mm

Number of Rows

1

Mounting Type

Through Hole

Gender

Male

Termination Method

Solder

Type

Base Strip

Current Rating

41A

Body Orientation

Straight

Colour

Green

Voltage Rating

1 kV

Series

PC

Depth

14.29mm

Width

29.25mm

Material

Polyamide

Length

18.04mm

COO (Country of Origin):
DE

Phoenix Contact 7.62mm COMBICON PC & PCV 5 Series Terminal Block Headers


7.62mm pitch COMBICON PC & PCV 5 series through hole mount PCB shrouded terminal block headers for use with COMBICON PC 5 plug connectors and suitable for 600 V UL when used with COMBICON PC 5 screw or spring cage plugs.
Stock numbers 803-2702, 803-2705 , 803-2709 and 803-2718 have a threaded flange for a vibration resistant connection.
Part numbers with a prefix of 17204 and 17205 are compatible with STCL plugs
All are PCB right angle mount apart from stock number 803-2718 which is PCB vertical mount

PCB headers, nominal cross section: 6 mm², color: green, nominal current: 41 A, rated voltage (III/2): 630 V, contact surface: Tin, type of contact: Male connector, Number of potentials: 2, Number of rows: 1, Number of positions per row: 2, number of connections: 2, product range: PC 5/..-G, pitch: 7.62 mm, mounting: Wave soldering, pin layout: Linear pinning, solder pin [P]: 5 mm, Stecksystem: POWER COMBICON 5, Locking: without, type of packaging: packed in cardboard


Phoenix Contact COMBICON 7.62mm Two Part Terminal Blocks

Approvals

UL94V-0
