Phoenix Contact ZFK3DS(A) 1.5 Series PCB Terminal Block, 7-Contact, 5.08 mm Pitch, 1 Row, 1934670
- RS Stock No.:
- 610-155
- Mfr. Part No.:
- 1934670
- Brand:
- Phoenix Contact
Subtotal (1 pack of 10 units)*
£113.97
(exc. VAT)
£136.76
(inc. VAT)
FREE delivery for orders over £60.00
Stocked by manufacturer
- Ready to ship from 23 July 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Pack(s) | Per Pack | Per unit* |
|---|---|---|
| 1 + | £113.97 | £11.397 |
*price indicative
- RS Stock No.:
- 610-155
- Mfr. Part No.:
- 1934670
- Brand:
- Phoenix Contact
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Phoenix Contact | |
| Product Type | PCB Terminal Block | |
| Number of Contacts | 7 | |
| Pitch | 5.08mm | |
| Number of Rows | 1 | |
| Current | 12A | |
| Housing Material | Polyamide | |
| Minimum Wire Size mm² | 0.2mm² | |
| Maximum Wire Size mm² | 2.5mm² | |
| Connector Gender | Female | |
| Minimum Wire Size AWG | 24AWG | |
| Maximum Wire Size AWG | 14AWG | |
| Orientation | 45° | |
| Wire Connection Method | Spring Cage | |
| Colour | Green | |
| Voltage | 40V | |
| Length | 32.2mm | |
| Series | ZFK3DS(A) 1.5 | |
| Standards/Approvals | IEC 60664-1:2007-04, EN 60695-2-12, EN 60695-2-13, UL 94 V0 | |
| Width | 36.56mm | |
| Select all | ||
|---|---|---|
Brand Phoenix Contact | ||
Product Type PCB Terminal Block | ||
Number of Contacts 7 | ||
Pitch 5.08mm | ||
Number of Rows 1 | ||
Current 12A | ||
Housing Material Polyamide | ||
Minimum Wire Size mm² 0.2mm² | ||
Maximum Wire Size mm² 2.5mm² | ||
Connector Gender Female | ||
Minimum Wire Size AWG 24AWG | ||
Maximum Wire Size AWG 14AWG | ||
Orientation 45° | ||
Wire Connection Method Spring Cage | ||
Colour Green | ||
Voltage 40V | ||
Length 32.2mm | ||
Series ZFK3DS(A) 1.5 | ||
Standards/Approvals IEC 60664-1:2007-04, EN 60695-2-12, EN 60695-2-13, UL 94 V0 | ||
Width 36.56mm | ||
- COO (Country of Origin):
- IN
The Phoenix Contact Printed circuit board terminal block offers a robust solution for connecting various electrical components while maintaining seamless performance and reliability. Designed for efficient integration into your applications, it boasts a nominal current handling capability of 12 A and a rated voltage of 400 V. Built with a distinctive green housing and a compact pitch of 5.08 mm, this component guarantees a reliable connection through its spring-cage mechanism, making it ideal for applications requiring high-density connections. Additionally, the terminal block is created to withstand extreme temperatures ranging from -40 °C to 100 °C, ensuring functionality in a range of environments.
Effective heat dissipation for enhanced operational safety
Long lasting material construction reducing maintenance needs
Convenient packaging aids in storage and transport efficiency
Highly versatile, suitable for various sectors and applications
