Phoenix Contact PC 6/..-ST Series PCB Terminal Block, 2-Contact, 10.16 mm Pitch, 1 Row, 1913507
- RS Stock No.:
- 610-033
- Mfr. Part No.:
- 1913507
- Brand:
- Phoenix Contact
Currently unavailable
We don't know if this item will be back in stock, RS intend to remove it from our range soon.
- RS Stock No.:
- 610-033
- Mfr. Part No.:
- 1913507
- Brand:
- Phoenix Contact
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Phoenix Contact | |
| Number of Contacts | 2 | |
| Product Type | PCB Terminal Block | |
| Pitch | 10.16mm | |
| Number of Rows | 1 | |
| Current | 41A | |
| Minimum Wire Size mm² | 0.5mm² | |
| Housing Material | Polyamide | |
| Connector Gender | Female | |
| Maximum Wire Size mm² | 1mm² | |
| Minimum Wire Size AWG | 18AWG | |
| Maximum Wire Size AWG | 8AWG | |
| Orientation | 0° | |
| Colour | Green | |
| Wire Connection Method | Screw Connection with Tension Sleeve | |
| Voltage | 1000V | |
| Series | PC 6/..-ST | |
| Standards/Approvals | cULus Recognised Approval ID:E60425-20010727, IEC 60068-2-6:2007-12, IEC 60068-2-70:1995-12, IEC 60512-1-1:2002-02, IEC 60512-1-2:2002-02, IEC 60512-13-2:2006-02, IEC 60512-13-5:2006-02, IEC 60999-1:1999-11, IEC 61984, ISO 6988:1985-02 | |
| Width | 19.36mm | |
| Length | 39mm | |
| Select all | ||
|---|---|---|
Brand Phoenix Contact | ||
Number of Contacts 2 | ||
Product Type PCB Terminal Block | ||
Pitch 10.16mm | ||
Number of Rows 1 | ||
Current 41A | ||
Minimum Wire Size mm² 0.5mm² | ||
Housing Material Polyamide | ||
Connector Gender Female | ||
Maximum Wire Size mm² 1mm² | ||
Minimum Wire Size AWG 18AWG | ||
Maximum Wire Size AWG 8AWG | ||
Orientation 0° | ||
Colour Green | ||
Wire Connection Method Screw Connection with Tension Sleeve | ||
Voltage 1000V | ||
Series PC 6/..-ST | ||
Standards/Approvals cULus Recognised Approval ID:E60425-20010727, IEC 60068-2-6:2007-12, IEC 60068-2-70:1995-12, IEC 60512-1-1:2002-02, IEC 60512-1-2:2002-02, IEC 60512-13-2:2006-02, IEC 60512-13-5:2006-02, IEC 60999-1:1999-11, IEC 61984, ISO 6988:1985-02 | ||
Width 19.36mm | ||
Length 39mm | ||
- COO (Country of Origin):
- PL
The Phoenix Contact PCB Connector is designed for optimal connectivity in demanding applications. Built with a nominal cross-section of 6 mm² and a striking green colour, it ensures reliability while handling currents up to 41 A. This connector is rated for a maximum voltage of 1000 V, making it suitable for a variety of industrial settings. Its robust design integrates a screw connection with a tension sleeve, allowing for quick and secure installation. This product is also compliant with WEEE and RoHS requirements, enhancing its appeal in environmentally-conscious workplaces.
Constructed to prevent incorrect insertion of conductors under the tension sleeve
Manufactured with WEEE and RoHS compliance for responsible environmental impact
Optimised design enhances efficiency with low temperature rise
Versatile conductor cross section accommodates both rigid and flexible connections
