WAGO 745 Series PCB Connector, 3-Contact, 7.5 mm Pitch, Through Hole, 1 Row
- RS Stock No.:
- 223-179
- Mfr. Part No.:
- 745-3153
- Brand:
- WAGO
Subtotal (1 box of 132 units)*
£266.64
(exc. VAT)
£319.97
(inc. VAT)
FREE delivery for orders over £60.00
Temporarily out of stock
- Shipping from 16 June 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Box(es) | Per Box | Per unit* |
|---|---|---|
| 1 + | £266.64 | £2.02 |
*price indicative
- RS Stock No.:
- 223-179
- Mfr. Part No.:
- 745-3153
- Brand:
- WAGO
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | WAGO | |
| Number of Contacts | 3 | |
| Product Type | PCB Connector | |
| Pitch | 7.5mm | |
| Current | 32A | |
| Number of Rows | 1 | |
| Minimum Wire Size mm² | 0.08mm² | |
| Housing Material | Polyamide 66 | |
| Mount Type | Through Hole | |
| Maximum Wire Size mm² | 4mm² | |
| Minimum Wire Size AWG | 28AWG | |
| Maximum Wire Size AWG | 12AWG | |
| Colour | Grey | |
| Wire Connection Method | Cage Clamp | |
| Voltage | 50V | |
| Standards/Approvals | No | |
| Series | 745 | |
| Depth | 19.4mm | |
| Width | 21.5mm | |
| Select all | ||
|---|---|---|
Brand WAGO | ||
Number of Contacts 3 | ||
Product Type PCB Connector | ||
Pitch 7.5mm | ||
Current 32A | ||
Number of Rows 1 | ||
Minimum Wire Size mm² 0.08mm² | ||
Housing Material Polyamide 66 | ||
Mount Type Through Hole | ||
Maximum Wire Size mm² 4mm² | ||
Minimum Wire Size AWG 28AWG | ||
Maximum Wire Size AWG 12AWG | ||
Colour Grey | ||
Wire Connection Method Cage Clamp | ||
Voltage 50V | ||
Standards/Approvals No | ||
Series 745 | ||
Depth 19.4mm | ||
Width 21.5mm | ||
- COO (Country of Origin):
- PL
The Wago PCB terminal block is designed to meet the needs of complex electronic systems, providing robust connectivity combined with versatility. Featuring a compact 3-pole configuration, it employs cutting-edge CAGE CLAMP technology for efficient and secure connections. Its thoughtful design includes a practical pin spacing of 7.5 mm, making it an ideal solution for space-constrained applications.
Allows for fine stranded conductor connections for versatile wiring options
Integrated testing tap enables convenient validation of electrical integrity
Meets high flammability standards for added safety in applications
Available with various accessories to further customise installation options
