WAGO 257 Series PCB Connector, 5-Contact, 10.16 mm Pitch, 1 Row, 257-655
- RS Stock No.:
- 221-630
- Mfr. Part No.:
- 257-655
- Brand:
- WAGO
Subtotal (1 box of 20 units)*
£37.37
(exc. VAT)
£44.84
(inc. VAT)
FREE delivery for orders over £60.00
Temporarily out of stock
- Shipping from 15 June 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Box(es) | Per Box | Per unit* |
|---|---|---|
| 1 + | £37.37 | £1.869 |
*price indicative
- RS Stock No.:
- 221-630
- Mfr. Part No.:
- 257-655
- Brand:
- WAGO
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | WAGO | |
| Number of Contacts | 5 | |
| Product Type | PCB Connector | |
| Pitch | 10.16mm | |
| Number of Rows | 1 | |
| Current | 24A | |
| Minimum Wire Size mm² | 0.08mm² | |
| Housing Material | Polyamide 66 | |
| Connector Gender | Male | |
| Maximum Wire Size mm² | 2.5mm² | |
| Minimum Wire Size AWG | 28AWG | |
| Maximum Wire Size AWG | 12AWG | |
| Colour | Grey | |
| Voltage | 63V | |
| Depth | 14.2mm | |
| Series | 257 | |
| Standards/Approvals | No | |
| Width | 52.9mm | |
| Select all | ||
|---|---|---|
Brand WAGO | ||
Number of Contacts 5 | ||
Product Type PCB Connector | ||
Pitch 10.16mm | ||
Number of Rows 1 | ||
Current 24A | ||
Minimum Wire Size mm² 0.08mm² | ||
Housing Material Polyamide 66 | ||
Connector Gender Male | ||
Maximum Wire Size mm² 2.5mm² | ||
Minimum Wire Size AWG 28AWG | ||
Maximum Wire Size AWG 12AWG | ||
Colour Grey | ||
Voltage 63V | ||
Depth 14.2mm | ||
Series 257 | ||
Standards/Approvals No | ||
Width 52.9mm | ||
- COO (Country of Origin):
- PL
The Wago PCB Terminal Block boasts a push button design, enabling quick and effortless in the field wiring. The CAGE CLAMP connection technology provides a secure and tool free operation, making it an ideal choice for a variety of applications. Designed for versatility, it accommodates both metric and inch pin spacing, allowing flexibility in installation. With multiple pole options and a robust construction from durable materials, this terminal block is also compliant with environmental standards, making it suitable for diverse commercial and industrial environments.
Constructed with high quality polyamide housing for excellent durability
Features a flammability rating of V0 for enhanced safety
Addresses multiple conductor types including solid and fine stranded options
Offers an impressive temperature range for reliable operation across environments
Includes variants that are compliant with various environmental regulations
