Molex MicroBlade Series Right Angle Through Hole PCB Header, 5 Contact(s), 2.0mm Pitch, 1 Row(s), Shrouded
- RS Stock No.:
- 688-2684
- Mfr. Part No.:
- 53015-0510
- Brand:
- Molex
Discontinued
- RS Stock No.:
- 688-2684
- Mfr. Part No.:
- 53015-0510
- Brand:
- Molex
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Molex | |
| Series | MicroBlade | |
| Pitch | 2.0mm | |
| Number of Contacts | 5 | |
| Number of Rows | 1 | |
| Body Orientation | Right Angle | |
| Shrouded/Unshrouded | Shrouded | |
| Mounting Type | Through Hole | |
| Connector System | Wire to Board | |
| Termination Method | Solder | |
| Contact Material | Phosphor Bronze | |
| Contact Plating | Tin | |
| Series Number | 53015 | |
| Current Rating | 2.0A | |
| Voltage Rating | 125.0 V | |
| Select all | ||
|---|---|---|
Brand Molex | ||
Series MicroBlade | ||
Pitch 2.0mm | ||
Number of Contacts 5 | ||
Number of Rows 1 | ||
Body Orientation Right Angle | ||
Shrouded/Unshrouded Shrouded | ||
Mounting Type Through Hole | ||
Connector System Wire to Board | ||
Termination Method Solder | ||
Contact Material Phosphor Bronze | ||
Contact Plating Tin | ||
Series Number 53015 | ||
Current Rating 2.0A | ||
Voltage Rating 125.0 V | ||
- COO (Country of Origin):
- KR
Right Angle Headers, 53015 Series
Mates with 51004 Series Crimp Housings
2.0mm Wire to Wire - Molex MicroBlade Range
Compact, low-profile size
Box-style contact gives protection to contact area
Friction lock provides good mating retention
Polarizing features ensures proper mating
Blade-type pins for reliability and good wipe length
Box-style contact gives protection to contact area
Friction lock provides good mating retention
Polarizing features ensures proper mating
Blade-type pins for reliability and good wipe length
