Wurth Elektronik WR-MPC3 Series Right Angle Surface Mount PCB Header, 2 Contact(s), 3.0mm Pitch, 1 Row(s), Shrouded
- RS Stock No.:
- 177-0044
- Mfr. Part No.:
- 662102136022
- Brand:
- Wurth Elektronik
Available to back order for despatch 09/09/2024
Added
Price Each
£2.34
(exc. VAT)
£2.81
(inc. VAT)
Units | Per unit |
1 - 9 | £2.34 |
10 - 49 | £2.10 |
50 - 99 | £1.90 |
100 - 249 | £1.76 |
250 + | £1.63 |
- RS Stock No.:
- 177-0044
- Mfr. Part No.:
- 662102136022
- Brand:
- Wurth Elektronik
Technical Reference
Legislation and Compliance
- COO (Country of Origin):
- TW
Product Details
Wurth Elektronik PCB Header
The Wurth Elektronik PCB WR-MPC3 series surface mount right-angle header has 2-way contacts. It has a voltage rating of 250VAC and a current rating of 5A. The header has tin-plated copper alloy contacts. This PCB Header is used in portable and handheld equipment.
Features and Benefits
• High reliability
• Operating temperature ranges between -40°C and 105°C
• Pitch size is 3mm
• Shrouded header
• Single row
• Termination method is solder
• Operating temperature ranges between -40°C and 105°C
• Pitch size is 3mm
• Shrouded header
• Single row
• Termination method is solder
Specifications
Attribute | Value |
---|---|
Series | WR-MPC3 |
Pitch | 3.0mm |
Number of Contacts | 2 |
Number of Rows | 1 |
Body Orientation | Right Angle |
Shrouded/Unshrouded | Shrouded |
Mounting Type | Surface Mount |
Connector System | Wire to Board |
Termination Method | Solder |
Contact Material | Copper Alloy |
Contact Plating | Tin |
Current Rating | 5.0A |
Series Number | 6621 |
Tail Pin Length | 1.45mm |
Voltage Rating | 250.0 V |
