Phoenix Contact CCV Series Straight Through Hole PCB Header, 6 Contact(s), 5.08 mm Pitch, 1 Row(s), Shrouded

View all PCB Headers

Subtotal (1 pack of 50 units)*

£117.50

(exc. VAT)

£141.00

(inc. VAT)

Add to Basket
Select or type quantity
Temporarily out of stock
  • Shipping from 19 January 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Pack(s)
Per Pack
Per unit*
1 +£117.50£2.35

*price indicative

RS Stock No.:
520-868
Mfr. Part No.:
1955426
Brand:
Phoenix Contact
Find similar products by selecting one or more attributes.
Select all

Brand

Phoenix Contact

Series

CCV

Product Type

PCB Header

Current

12A

Pitch

5.08mm

Number of Contacts

6

Housing Material

Liquid Crystal Polymer

Number of Rows

1

Orientation

Straight

Shrouded/Unshrouded

Shrouded

Mount Type

Through Hole

Connector System

COMBICON MSTB 2.5

Contact Plating

Tin Plated

Contact Material

Copper Alloy

Minimum Operating Temperature

-40°C

Termination Type

Solder

Row Pitch

5.08mm

Maximum Operating Temperature

100°C

Tail Pin Length

2.6mm

Contact Gender

Male

Standards/Approvals

cULus Recognised, IEC 60068-2-70:1995-12, IEC 60512-1-1:2002-02, IEC 60512-1-2:2002-02, IEC 60512-13-5:2006-02, IEC 60512-15-1:2008-05, IEC 60512-3-1:2002-02, IEC 60512-5-1:2002-02, IEC 60664-1:2007-04, ISO 6988:1985-02, VDE

Mating Pin Length

2.6mm

Voltage

32 V

COO (Country of Origin):
DE
The Phoenix Contact CCV 2.5/ 6-G-5.08 P26THR is a high-quality PCB header designed for seamless integration into modern electronic applications. Built for efficiency, this component supports a nominal current of 12 A and offers a rated voltage of 320 V. Its innovative design facilitates through-hole reflow technology, making it an excellent choice for streamlined assembly processes. With a pitch of 5.08 mm and a linear pinning layout, this header ensures reliable connectivity in compact spaces. The black housing not only provides a sleek appearance but also meets stringent flammability ratings and moisture sensitivity levels. Suitable for wave soldering and reflow processes, this product ensures longevity and robustness in various environments, making it an ideal solution for a wide range of devices, from consumer electronics to industrial applications.

Offers maximum flexibility for device design with a single header accommodating various connector technologies

Supports vertical connections, enabling efficient multi-row arrangements on the PCB

Constructed to meet WEEE/RoHS compliance, ensuring environmentally safe operation

Utilises robust materials that withstand the demands of reflow soldering processes

Delivers exceptional contact resistance and insulation properties to optimise electronic performance

Designed for easy mounting with a simple linear pin layout aiding in user-friendly assembly

Features generous solder pins and adaptable dimensions to fit standard PCB designs
