Renesas, PS8902-Y-V-AX Photodiode Output Optocoupler, Surface Mount, 8-Pin DIP
- RS Stock No.:
- 186-4452
- Mfr. Part No.:
- PS8902-Y-V-AX
- Brand:
- Renesas Electronics
Currently unavailable
We don’t know if this item will be back in stock, it is being discontinued by the manufacturer.
- RS Stock No.:
- 186-4452
- Mfr. Part No.:
- PS8902-Y-V-AX
- Brand:
- Renesas Electronics
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Renesas Electronics | |
| Mounting Type | Surface Mount | |
| Output Device | Photodiode | |
| Maximum Forward Voltage | 1.85V | |
| Number of Channels | 1 | |
| Number of Pins | 8 | |
| Package Type | DIP | |
| Typical Rise Time | 0.5µs | |
| Maximum Input Current | 16 mA | |
| Isolation Voltage | 7.5 kVrms | |
| Maximum Current Transfer Ratio | 35% | |
| Minimum Current Transfer Ratio | 15% | |
| Typical Fall Time | 0.3µs | |
Select all | ||
|---|---|---|
Brand Renesas Electronics | ||
Mounting Type Surface Mount | ||
Output Device Photodiode | ||
Maximum Forward Voltage 1.85V | ||
Number of Channels 1 | ||
Number of Pins 8 | ||
Package Type DIP | ||
Typical Rise Time 0.5µs | ||
Maximum Input Current 16 mA | ||
Isolation Voltage 7.5 kVrms | ||
Maximum Current Transfer Ratio 35% | ||
Minimum Current Transfer Ratio 15% | ||
Typical Fall Time 0.3µs | ||
- COO (Country of Origin):
- JP
High-speed analogue output photocouplers (optocouplers) are optically coupled isolators containing a GaAlAs LED on the input side and a PIN photodiode and high-speed amplifier transistor on the output side in a single chip.
The PS8902 is an optically coupled isolator containing a GaAlAs LED on the light emitting diode (input side) and a PIN photodiode and a high-speed amplifier transistor on the output side on one chip.
Long creepage distance (14.5 mm MIN.)
8-pin LSDIP (Long Creepage SDIP) type
High-speed response (tPHL = 0.8 s MAX., tPLH = 1.2 s MAX.)
High common mode transient immunity (CMH, CML = 15 kV/s MIN.)
Pb-Free Product
APPLICATIONS
Power supply
Computer and peripheral manufactures
General purpose inverter
Substitutions for relays and pulse transformers
8-pin LSDIP (Long Creepage SDIP) type
High-speed response (tPHL = 0.8 s MAX., tPLH = 1.2 s MAX.)
High common mode transient immunity (CMH, CML = 15 kV/s MIN.)
Pb-Free Product
APPLICATIONS
Power supply
Computer and peripheral manufactures
General purpose inverter
Substitutions for relays and pulse transformers
