TSV7722IST STMicroelectronics, Operational Amplifier, 22 MHz, 8-Pin 5.5V SO
- RS Stock No.:
- 216-7880
- Mfr. Part No.:
- TSV7722IST
- Brand:
- STMicroelectronics
Bulk discount available
Subtotal (1 pack of 10 units)*
£5.98
(exc. VAT)
£7.18
(inc. VAT)
FREE delivery for orders over £60.00
Temporarily out of stock
- Shipping from 28 October 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Pack* |
|---|---|---|
| 10 - 40 | £0.598 | £5.98 |
| 50 - 90 | £0.59 | £5.90 |
| 100 - 490 | £0.583 | £5.83 |
| 500 + | £0.576 | £5.76 |
*price indicative
- RS Stock No.:
- 216-7880
- Mfr. Part No.:
- TSV7722IST
- Brand:
- STMicroelectronics
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | STMicroelectronics | |
| Product Type | Operational Amplifier | |
| Mount Type | Surface | |
| Package Type | SO | |
| Number of Channels | 2 | |
| Pin Count | 8 | |
| GBP - Gain Bandwidth Product | 22MHz | |
| Minimum Supply Voltage | 5.5V | |
| Maximum Supply Voltage | 5.5V | |
| Slew Rate | 11V/μs | |
| Vos - Input Offset Voltage | 650 μV | |
| Input Bias Current | 20 pA | |
| Minimum Operating Temperature | -40°C | |
| Maximum Operating Temperature | 125°C | |
| Height | 1.75mm | |
| Standards/Approvals | RoHS | |
| Length | 5mm | |
| Series | TSV7722 | |
| Output Current | 40mA | |
| Automotive Standard | AEC-Q100 | |
| Input Offset Current | 75 pA | |
| Select all | ||
|---|---|---|
Brand STMicroelectronics | ||
Product Type Operational Amplifier | ||
Mount Type Surface | ||
Package Type SO | ||
Number of Channels 2 | ||
Pin Count 8 | ||
GBP - Gain Bandwidth Product 22MHz | ||
Minimum Supply Voltage 5.5V | ||
Maximum Supply Voltage 5.5V | ||
Slew Rate 11V/μs | ||
Vos - Input Offset Voltage 650 μV | ||
Input Bias Current 20 pA | ||
Minimum Operating Temperature -40°C | ||
Maximum Operating Temperature 125°C | ||
Height 1.75mm | ||
Standards/Approvals RoHS | ||
Length 5mm | ||
Series TSV7722 | ||
Output Current 40mA | ||
Automotive Standard AEC-Q100 | ||
Input Offset Current 75 pA | ||
The STMicroelectronics TSV7722IST is a single and dual 22 MHz-bandwidth unity gain- stable amplifier. The input offset voltage of 200 μV max at room temperature, optimized for common-mode close to ground makes the TSV7722IST ideal for low-side current measurements.
High accuracy input offset voltage
Low input bias current
Low input voltage noise density
