    CA3140MZ Renesas Electronics, Op Amp, 3.7MHz, 5 → 28 V, 8-Pin SOIC

    RS Stock No.:
    169-8298
    Mfr. Part No.:
    CA3140MZ
    Brand:
    Renesas Electronics
    Renesas Electronics
    View all Op Amps
    Sorry, we couldn't check our stock levels right now. Please try refreshing the page.
    Add to Basket
    Units

    Not available for guaranteed pre 9am/10am delivery

    Added

    Price Each (In a Tube of 98)

    £2.225

    (exc. VAT)

    £2.67

    (inc. VAT)

    UnitsPer unitPer Tube*
    98 - 392£2.225£218.05
    490 - 882£2.14£209.72
    980 +£2.084£204.232
    *price indicative
    RS Stock No.:
    169-8298
    Mfr. Part No.:
    CA3140MZ
    Brand:
    Renesas Electronics

    Non Compliant

    Legislation and Compliance

    Non Compliant


    Product Details

    CA3140, CA3140A, 4.5MHz, BiMOS Operational Amplifier with MOSFET Input / Bipolar Output, Intersil


    MOSFET input stage provides High Input Impedance with Low-Input Current
    Wide Common Mode Input Voltage range


    Operational Amplifiers, Intersil


    Intersil Operational Amplifiers are among high-performance amplifier ICs in the industry.

    Specifications

    AttributeValue
    Mounting TypeSurface Mount
    Package TypeSOIC
    Power Supply TypeDual, Single
    Number of Channels per Chip1
    Pin Count8
    Typical Single Supply Voltage5 → 28 V
    Typical Gain Bandwidth Product3.7MHz
    Typical Dual Supply Voltage±12 V, ±15 V, ±3 V, ±5 V, ±9 V
    Typical Slew Rate7V/µs
    Minimum Operating Temperature-55 °C
    Maximum Operating Temperature+125 °C
    Rail to RailNo
    Typical Voltage Gain100 dB
    Height1.5mm
    Width4mm
    Length5mm
    Dimensions5 x 4 x 1.5mm
    Typical Input Voltage Noise Density40nV/√Hz
