LF347DT STMicroelectronics, JFET, Op Amp, 4MHz, 14-Pin SOIC
- RS Stock No.:
- 165-5518
- Mfr. Part No.:
- LF347DT
- Brand:
- STMicroelectronics
Currently unavailable
We don’t know if this item will be back in stock, it is being discontinued by the manufacturer.
- RS Stock No.:
- 165-5518
- Mfr. Part No.:
- LF347DT
- Brand:
- STMicroelectronics
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | STMicroelectronics | |
| Amplifier Type | JFET | |
| Mounting Type | Surface Mount | |
| Package Type | SOIC | |
| Power Supply Type | Dual | |
| Number of Channels per Chip | 4 | |
| Pin Count | 14 | |
| Typical Gain Bandwidth Product | 4MHz | |
| Typical Dual Supply Voltage | ±15V | |
| Typical Slew Rate | 16V/µs | |
| Minimum Operating Temperature | 0 °C | |
| Maximum Operating Temperature | +70 °C | |
| Output Current | 60 mA | |
| Typical Voltage Gain | 106 dB | |
| Maximum Input Voltage | 18 V | |
| Rail to Rail | No | |
| Offset Voltage | 13mV | |
| Typical Input Voltage Noise Density | 15nV/√Hz | |
| Minimum Input Voltage | -18 V | |
| Length | 8.75mm | |
| Input Offset Current | 4nA | |
| Height | 1.6mm | |
| Width | 4mm | |
| Input Voltage Range | ±18 V | |
| Dimensions | 8.75 x 4 x 1.6mm | |
Select all | ||
|---|---|---|
Brand STMicroelectronics | ||
Amplifier Type JFET | ||
Mounting Type Surface Mount | ||
Package Type SOIC | ||
Power Supply Type Dual | ||
Number of Channels per Chip 4 | ||
Pin Count 14 | ||
Typical Gain Bandwidth Product 4MHz | ||
Typical Dual Supply Voltage ±15V | ||
Typical Slew Rate 16V/µs | ||
Minimum Operating Temperature 0 °C | ||
Maximum Operating Temperature +70 °C | ||
Output Current 60 mA | ||
Typical Voltage Gain 106 dB | ||
Maximum Input Voltage 18 V | ||
Rail to Rail No | ||
Offset Voltage 13mV | ||
Typical Input Voltage Noise Density 15nV/√Hz | ||
Minimum Input Voltage -18 V | ||
Length 8.75mm | ||
Input Offset Current 4nA | ||
Height 1.6mm | ||
Width 4mm | ||
Input Voltage Range ±18 V | ||
Dimensions 8.75 x 4 x 1.6mm | ||
- COO (Country of Origin):
- MA
LF347, LF351, LF353, JFET Inputs, Low Input Bias & Offset Current Operational Amplifiers
The LF347, LF351 and LF353 are high-speed JFET input operational amplifiers that incorporate matched, high-voltage JFET and bipolar transistors. They feature high slew rates, low input bias and offset currents, and low offset voltage temperature coefficient.
