Schurter Surface Mount Fuse 1 A, 250 V ac
- RS Stock No.:
- 270-7953
- Mfr. Part No.:
- 3404.2416.11
- Brand:
- Schurter
Subtotal (1 unit)*
£1.32
(exc. VAT)
£1.58
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 22 May 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £1.32 |
*price indicative
- RS Stock No.:
- 270-7953
- Mfr. Part No.:
- 3404.2416.11
- Brand:
- Schurter
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Schurter | |
| Current Rating | 1 A | |
| Product Type | Surface Mount Fuse | |
| Voltage | 250 V ac | |
| Fuse Speed | Time Lag | |
| Body Material | Ceramic | |
| Width | 11.1 mm | |
| Height | 4.2mm | |
| Fuse Characteristics | Time Lag | |
| Minimum Operating Temperature | -40°C | |
| Breaking Capacity | 200A | |
| Maximum Operating Temperature | 85°C | |
| Standards/Approvals | IEC 60127-6, IEC 60127-4, UL 248-14 / 4248-1, CSA22.2 No. 248.14 / No. 4248.1 | |
| Series | UMZ 250 | |
| Package Size | 4.2 x 11.1 mm | |
| Terminal Material | Gold Plated Copper | |
| Select all | ||
|---|---|---|
Brand Schurter | ||
Current Rating 1 A | ||
Product Type Surface Mount Fuse | ||
Voltage 250 V ac | ||
Fuse Speed Time Lag | ||
Body Material Ceramic | ||
Width 11.1 mm | ||
Height 4.2mm | ||
Fuse Characteristics Time Lag | ||
Minimum Operating Temperature -40°C | ||
Breaking Capacity 200A | ||
Maximum Operating Temperature 85°C | ||
Standards/Approvals IEC 60127-6, IEC 60127-4, UL 248-14 / 4248-1, CSA22.2 No. 248.14 / No. 4248.1 | ||
Series UMZ 250 | ||
Package Size 4.2 x 11.1 mm | ||
Terminal Material Gold Plated Copper | ||
- COO (Country of Origin):
- CH
The Schurter Surface Mount Fuse is made by ceramic material with having a gold plated copper alloy terminal. This fuse directly solderable on printed circuit boards. This surface mount fuse has high breaking capacity of 200 A at 250 VAC according to IEC standard with UL approval for 0.08 A to 4 A at 277 VAC and 250 VDC.
Compact design
Maximum breaking capacity at minimal footprint
VDE and UL Approvals UMT 250
Provides primary protection on SMD PCBs
