Schurter Surface Mount Fuse 2.5 A, 125 V ac
- RS Stock No.:
- 270-7950
- Mfr. Part No.:
- 3404.0117.11
- Brand:
- Schurter
Subtotal (1 unit)*
£1.00
(exc. VAT)
£1.20
(inc. VAT)
Stock information currently inaccessible - Please check back later
Units | Per unit |
|---|---|
| 1 + | £1.00 |
*price indicative
- RS Stock No.:
- 270-7950
- Mfr. Part No.:
- 3404.0117.11
- Brand:
- Schurter
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Schurter | |
| Product Type | Surface Mount Fuse | |
| Current Rating | 2.5 A | |
| Voltage | 125 V ac | |
| Fuse Speed | Time Lag | |
| Body Material | Thermoplastic | |
| Width | 3.1 mm | |
| Height | 7.4mm | |
| Minimum Operating Temperature | -40°C | |
| Fuse Characteristics | Time Lag | |
| Package Type | Bulk Bag | |
| Breaking Capacity | 100A | |
| Maximum Operating Temperature | 85°C | |
| Depth | 2.6mm | |
| Standards/Approvals | RoHS, CSA. . 48.14, CE, REACH, UKCA, IECUL 6681, UL 4814 | |
| Series | OMT 125 | |
| Package Size | 7.4 x 3.1 mm | |
| Resistance | 100mΩ | |
| Terminal Material | Tin Plated, Copper | |
| Select all | ||
|---|---|---|
Brand Schurter | ||
Product Type Surface Mount Fuse | ||
Current Rating 2.5 A | ||
Voltage 125 V ac | ||
Fuse Speed Time Lag | ||
Body Material Thermoplastic | ||
Width 3.1 mm | ||
Height 7.4mm | ||
Minimum Operating Temperature -40°C | ||
Fuse Characteristics Time Lag | ||
Package Type Bulk Bag | ||
Breaking Capacity 100A | ||
Maximum Operating Temperature 85°C | ||
Depth 2.6mm | ||
Standards/Approvals RoHS, CSA. . 48.14, CE, REACH, UKCA, IECUL 6681, UL 4814 | ||
Series OMT 125 | ||
Package Size 7.4 x 3.1 mm | ||
Resistance 100mΩ | ||
Terminal Material Tin Plated, Copper | ||
- COO (Country of Origin):
- CH
The Schurter Surface Mount Fuse is made by thermoplastic material with UL 94V 0 standard with having a copper alloy and tin plated terminal. This fuse directly solderable on printed circuit boards. This surface mount fuse support time lag T type of force.
Reflow and wave soldering methods
MSL 1 and J STD 020 moisture sensitivity level
Solderability according to IEC 60068 2 58
Terminal strength MIL STD 202 and Method 211 A
