Bourns Non-Resettable Fuse 315mA, 125V ac

Name: Bourns Non-Resettable Fuse 315mA, 125V ac
Brand: Bourns
SKU: 191-4597
Availability: OutOfStock

Currently unavailable

Sorry, we don't know when this will be back in stock.

Specifications

Technical Reference

Legislation and Compliance

Product Details

Find similar products by selecting one or more attributes.

Select all	Attribute	Value
	Brand	Bourns
	Current Rating	315mA
	Product Type	Non-Resettable Fuse
	Voltage	125V ac
	Fuse Speed	FP
	Body Material	Ceramic
	Width	2.6mm
	Height	2.6mm
	Fuse Characteristics	Fast Acting
	Minimum Operating Temperature	125°C
	Breaking Capacity	300A
	Maximum Operating Temperature	-55°C
	Package Type	Reel
	Standards/Approvals	UL 248-14, RoHS
	Depth	6.1mm
	Package Size	2410
	Series	SF-2410FP-T
	Resistance	843mΩ

	Select all
	Brand Bourns
	Current Rating 315mA
	Product Type Non-Resettable Fuse
	Voltage 125V ac
	Fuse Speed FP
	Body Material Ceramic
	Width 2.6mm
	Height 2.6mm
	Fuse Characteristics Fast Acting
	Minimum Operating Temperature 125°C
	Breaking Capacity 300A
	Maximum Operating Temperature -55°C
	Package Type Reel
	Standards/Approvals UL 248-14, RoHS
	Depth 6.1mm
	Package Size 2410
	Series SF-2410FP-T
	Resistance 843mΩ

Single blow fuse for overcurrent protection

Ceramic tube design for fast acting precision fusing speed applications

Surface mount packaging for automated assembly

Halogen free

Applications

Notebooks

LCD Monitors

LCD Backlight Inverters

POE, POE+

PC Servers

Power Supplies

Game Consoles

White Goods
