Telemecanique Sensors XCSDMP Series Magnetic Safety Switch, Plastic Housing, 100V dc, NO, 3 NC, 10 m Cable
- RS Stock No.:
- 133-0073
- Mfr. Part No.:
- XCSDMP70010
- Brand:
- Telemecanique Sensors
Subtotal (1 unit)*
£123.70
(exc. VAT)
£148.44
(inc. VAT)
FREE delivery for orders over £60.00
Temporarily out of stock
- 9 unit(s) shipping from 19 August 2026
- Plus 16 unit(s) shipping from 16 September 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £123.70 |
*price indicative
- RS Stock No.:
- 133-0073
- Mfr. Part No.:
- XCSDMP70010
- Brand:
- Telemecanique Sensors
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Telemecanique Sensors | |
| Product Type | Safety Switch | |
| Safety Contacts | NO, 3 NC | |
| Body Style | Rectangular | |
| Housing Material | Plastic | |
| Connection Type | 10 m Cable | |
| Actuator Type | Coded | |
| Sensor Principle | Magnetic | |
| Housing Colour | Red | |
| Safety Category | ISO 13849-1 | |
| Terminal Type | Cable | |
| Switching Current | 100mA | |
| Actuator Included | Yes | |
| Switching Distance | 20 mm | |
| Series | XCSDMP | |
| Switching DC Voltage | 100V dc | |
| IP Rating | IP66, IP67 | |
| Standards/Approvals | CSA, CSA C22.2 No. 14, UL, UL 508, EN/ISO 12100, EN/IEC 60947-5-1, BG, EN/IEC 60204-1 | |
| Width | 25mm | |
| Hazardous Area Certification | No | |
| Length | 25mm | |
| Depth | 88mm | |
| Select all | ||
|---|---|---|
Brand Telemecanique Sensors | ||
Product Type Safety Switch | ||
Safety Contacts NO, 3 NC | ||
Body Style Rectangular | ||
Housing Material Plastic | ||
Connection Type 10 m Cable | ||
Actuator Type Coded | ||
Sensor Principle Magnetic | ||
Housing Colour Red | ||
Safety Category ISO 13849-1 | ||
Terminal Type Cable | ||
Switching Current 100mA | ||
Actuator Included Yes | ||
Switching Distance 20 mm | ||
Series XCSDMP | ||
Switching DC Voltage 100V dc | ||
IP Rating IP66, IP67 | ||
Standards/Approvals CSA, CSA C22.2 No. 14, UL, UL 508, EN/ISO 12100, EN/IEC 60947-5-1, BG, EN/IEC 60204-1 | ||
Width 25mm | ||
Hazardous Area Certification No | ||
Length 25mm | ||
Depth 88mm | ||
RoHS Status: Exempt
Telemecanique Sensors XCSDMP Series Safety Switch, 20mm Switching Distance, Red Housing - XCSDMP70010
This safety switch provides monitored access control for machinery and guarded areas, using a coded actuator and magnetic sensing to detect actuation reliably. It is housed in a red plastic enclosure with an integrated actuator and a pre-fitted cable connection, designed for use where personnel protection and machine stoppage are required.
Features and Benefits:
• IP66 and IP67 ingress protection enables operation in wet environments
• Magnetic sensing allows contactless detection up to 20mm
• Three normally closed contacts provide discrete safety signalling
• Pre-cabled termination simplifies installation and reduces wiring time
• Accepts up to 100V DC and switches currents up to 100 mA for control circuits
• Certified to multiple standards for industrial safety integration
• Magnetic sensing allows contactless detection up to 20mm
• Three normally closed contacts provide discrete safety signalling
• Pre-cabled termination simplifies installation and reduces wiring time
• Accepts up to 100V DC and switches currents up to 100 mA for control circuits
• Certified to multiple standards for industrial safety integration
Applications
• Suitable for interlocking access doors on production machinery
• Ideal for safety Gates on automated assembly lines
• Used for guard monitoring in packaging and material handling
• Can be used for control circuit isolation in electrical enclosures
• Ideal for safety Gates on automated assembly lines
• Used for guard monitoring in packaging and material handling
• Can be used for control circuit isolation in electrical enclosures
What connection format does it use for installation?
It is supplied with a fixed cable tail for direct wiring into control panels or conduits without removable terminals.
How many switching elements are provided for safety logic?
The unit includes three normally closed contacts, enabling direct integration with safety relay or safety controller inputs.
What construction ensures visibility and Basic impact resistance?
The enclosure is moulded from plastic and finished in red to aid identification on the shop floor while providing Basic mechanical protection.
Which approvals indicate suitability for industrial electrical systems?
It carries approvals from recognised bodies including CSA and UL and meets relevant EN/IEC standards for safety and machine control.
