Texas Instruments DRV8823DCA, Stepper Motor Driver IC, 32 V 1A 48-Pin, HTSSOP
- RS Stock No.:
- 162-6148
- Mfr. Part No.:
- DRV8823DCA
- Brand:
- Texas Instruments
Currently unavailable
We don’t know if this item will be back in stock, it is being discontinued by the manufacturer.
- RS Stock No.:
- 162-6148
- Mfr. Part No.:
- DRV8823DCA
- Brand:
- Texas Instruments
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | Texas Instruments | |
Motor Type | Stepper | |
Output Configuration | Quad Full Bridge | |
Maximum IGBT Collector Current | 1A | |
Maximum Collector Emitter Voltage | 32 V | |
Mounting Type | Surface Mount | |
Package Type | HTSSOP | |
Pin Count | 48 | |
Maximum Operating Supply Voltage | 32 V | |
Minimum Operating Supply Voltage | 8 V | |
Typical Switching Frequency | 50kHz | |
Inverter Power Rating | 5.61W | |
Height | 1.05mm | |
Width | 6.2mm | |
Length | 12.6mm | |
Minimum Operating Temperature | -40 °C | |
Dimensions | 12.6 x 6.2 x 1.05mm | |
Priced to Clear | Yes | |
Maximum Operating Temperature | +85 °C | |
Select all | ||
---|---|---|
Brand Texas Instruments | ||
Motor Type Stepper | ||
Output Configuration Quad Full Bridge | ||
Maximum IGBT Collector Current 1A | ||
Maximum Collector Emitter Voltage 32 V | ||
Mounting Type Surface Mount | ||
Package Type HTSSOP | ||
Pin Count 48 | ||
Maximum Operating Supply Voltage 32 V | ||
Minimum Operating Supply Voltage 8 V | ||
Typical Switching Frequency 50kHz | ||
Inverter Power Rating 5.61W | ||
Height 1.05mm | ||
Width 6.2mm | ||
Length 12.6mm | ||
Minimum Operating Temperature -40 °C | ||
Dimensions 12.6 x 6.2 x 1.05mm | ||
Priced to Clear Yes | ||
Maximum Operating Temperature +85 °C | ||
- COO (Country of Origin):
- TW
Stepper Drivers with FETs, Texas Instruments
A range of dedicated Stepper Motor Driver ICs from Texas Instruments.
Motor Controllers & Drivers, Texas Instruments
