Amphenol Air LB, PT, Copper Alloy Straight 26 Way Hole Circular Connector Female Silver, Female Contacts,Shell Size 16,
- RS Stock No.:
- 251-2644
- Mfr. Part No.:
- VG95328T16-26SN
- Brand:
- Amphenol Air LB
Bulk discount available
Subtotal (1 unit)*
£59.03
(exc. VAT)
£70.84
(inc. VAT)
FREE delivery for orders over £60.00
Temporarily out of stock
- Shipping from 17 November 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 - 9 | £59.03 |
| 10 - 24 | £57.37 |
| 25 - 49 | £55.13 |
| 50 - 99 | £53.42 |
| 100 + | £52.00 |
*price indicative
- RS Stock No.:
- 251-2644
- Mfr. Part No.:
- VG95328T16-26SN
- Brand:
- Amphenol Air LB
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Amphenol Air LB | |
| Product Type | Circular Connector | |
| Number of Contacts | 26 | |
| Current | 40A | |
| Contact Gender | Female | |
| Connector Gender | Female | |
| Voltage | 850V | |
| Shell Size | 16 | |
| Mount Type | Hole | |
| Military Standard | MIL-DTL-26482 | |
| IP Rating | IP68 | |
| Minimum Operating Temperature | -55°C | |
| Mating Type | Bayonet | |
| Termination Type | Solder | |
| Maximum Operating Temperature | 125°C | |
| Orientation | Straight | |
| Standards/Approvals | RoHS, REACH | |
| Series | PT | |
| Housing Material | Aluminium Alloy | |
| Strain Relief | No | |
| Contact Plating | Cadmium | |
| Colour | Silver | |
| Contact Material | Copper Alloy | |
| Select all | ||
|---|---|---|
Brand Amphenol Air LB | ||
Product Type Circular Connector | ||
Number of Contacts 26 | ||
Current 40A | ||
Contact Gender Female | ||
Connector Gender Female | ||
Voltage 850V | ||
Shell Size 16 | ||
Mount Type Hole | ||
Military Standard MIL-DTL-26482 | ||
IP Rating IP68 | ||
Minimum Operating Temperature -55°C | ||
Mating Type Bayonet | ||
Termination Type Solder | ||
Maximum Operating Temperature 125°C | ||
Orientation Straight | ||
Standards/Approvals RoHS, REACH | ||
Series PT | ||
Housing Material Aluminium Alloy | ||
Strain Relief No | ||
Contact Plating Cadmium | ||
Colour Silver | ||
Contact Material Copper Alloy | ||
Non Compliant
- COO (Country of Origin):
- DE
The Amphenol Air LB is shielded with bayonet locking is well suited for new technologies in the industrial and military sectors as well as aerospace applications where size, weight and reliability are of crucial importance.
Medium contact density
Handles strong vibrations levels
