Amphenol Limited, 62GB 41 Way Cable MIL Spec Circular Connector Receptacle, Pin Contacts,Shell Size 20, Bayonet,
- RS Stock No.:
- 200-5325
- Mfr. Part No.:
- 62GB-51T20-41PN
- Brand:
- Amphenol Limited
63 In stock - FREE next working day delivery available
2 available from Europe for delivery within 2 working day(s).
Price Each
£104.44
(exc. VAT)
£125.33
(inc. VAT)
Units | Per unit |
---|---|
1 - 9 | £104.44 |
10 + | £96.19 |
- RS Stock No.:
- 200-5325
- Mfr. Part No.:
- 62GB-51T20-41PN
- Brand:
- Amphenol Limited
Technical Reference
Legislation and Compliance
- COO (Country of Origin):
- GB
Product Details
The Amphenol 62GB series connector brings the advantage of keyway orientation to reduce mismating around multiple connectors. They feature aluminium shells with brass or stainless steel options available. A resilient neoprene insulator integrated rear wire sealing grommet guarantees a liquid tight assembly.
Temperature operating range : -55°C to 125°C
Wire gauges and current carrying capabilities : Upto 45A and size 24 to 8 AWG wires
Connectors contacts are gold plated
Wire gauges and current carrying capabilities : Upto 45A and size 24 to 8 AWG wires
Connectors contacts are gold plated
Specifications
Attribute | Value |
---|---|
Number of Contacts | 41 |
Gender | Female |
Contact Gender | Male |
Current Rating | 7.5A |
Voltage Rating | 700 V |
Shell Size | 20 |
Mounting Type | Cable |
Military Standard | MIL-DTL-26482 |
Mating Type | Bayonet |
Body Orientation | Straight |
Series | 62GB |
