Amphenol 451 Series, 3 Way Cable Mount MIL Spec Circular Connector Plug, Pin Contacts,Shell Size 8, Bayonet Coupling

  • RS Stock No. 178-7809
  • Mfr. Part No. 45106EC83AP50
  • Brand Amphenol
Technical Reference
Legislation and Compliance
Non Compliant
Product Details

Cable Mount

This military grade cable mount plug connector features bayonet coupling for quick and reliable connection as well as a cable clamp back shell. A very durable connector suitable for industrial applications, this connector is available in a variety of shell sizes and contact configurations.

Dimensions (mm)
Contact arrangement L. D. Max. cable dia.
10-6P/S 46 22 4.5
14-12P/S 46 28 9.3
14-19P/S 46 28 9.3
16-26P/S 49 32 12.5
18-32P/S 49 35 15.6
//media.rs-online.com/t_line/L340151-01.gif
Total Current Rating per Connector 5A ´ no. of contacts
Current Rating per Contact 7.5A
Max. Working Voltage 700 Vac r.m.s. or 850Vdc
Breakdown Voltage 1.5kVac min
Contact Resistance 7mΩ at 7.5 A
Insulation Resistance at 500Vdc 5´109Ω
Temperature Range -55 → +125°C
Wire Size, size 16 contacts 16-20 AWG
Wire Size, size 20 contacts 20-24 AWG
Specifications
Attribute Value
Number of Contacts 3
Gender Male
Contact Gender Male
Current Rating 7.5A
Shell Size 8
Mounting Type Cable Mount
Termination Method Solder
Mating Type Bayonet Coupling
Body Orientation Straight
Series 451
Strain Relief Yes
Contact Plating Gold
Maximum Operating Temperature +125°C
Minimum Operating Temperature -55°C
Shell Plating Olive Drab Cadmium
62 In stock for FREE next working day delivery
Price Each
£ 25.00
(exc. VAT)
£ 30.00
(inc. VAT)
Units
Per unit
1 - 9
£25.00
10 - 24
£23.53
25 - 49
£22.05
50 +
£21.65
