Hirose 9 Way Right Angle SD Card Memory Card Connector With Solder Termination
- RS Stock No.:
- 502-5010
- Mfr. Part No.:
- DM1B-DSF-PEJ
- Brand:
- Hirose
Discontinued
- RS Stock No.:
- 502-5010
- Mfr. Part No.:
- DM1B-DSF-PEJ
- Brand:
- Hirose
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Hirose | |
| Card Type | SD Card | |
| Gender | Female | |
| Number of Contacts | 9 | |
| Number of Rows | 1 | |
| Pitch | 2.5mm | |
| Body Orientation | Right Angle | |
| Mounting Type | Surface Mount | |
| Contact Material | Phosphor Bronze | |
| Contact Plating | Gold | |
| Termination Method | Solder | |
| Housing Material | Thermoplastic | |
| Length | 29.9mm | |
| Width | 28mm | |
| Depth | 2.9mm | |
| Maximum Operating Temperature | +85°C | |
| Minimum Operating Temperature | -25°C | |
| Dimensions | 28 x 2.9 x 29.9mm | |
| Select all | ||
|---|---|---|
Brand Hirose | ||
Card Type SD Card | ||
Gender Female | ||
Number of Contacts 9 | ||
Number of Rows 1 | ||
Pitch 2.5mm | ||
Body Orientation Right Angle | ||
Mounting Type Surface Mount | ||
Contact Material Phosphor Bronze | ||
Contact Plating Gold | ||
Termination Method Solder | ||
Housing Material Thermoplastic | ||
Length 29.9mm | ||
Width 28mm | ||
Depth 2.9mm | ||
Maximum Operating Temperature +85°C | ||
Minimum Operating Temperature -25°C | ||
Dimensions 28 x 2.9 x 29.9mm | ||
RoHS Status: Not Applicable
- COO (Country of Origin):
- ID
SD card connector
Designed to accept SD and MMC card types
Absorbs excessive stress in the card insertion direction
Prevents the card from being damaged in an attempt to remove forcibly
Accidental card fall-out prevention
Suitable for notebook PCs, digital cameras and PDAs
Absorbs excessive stress in the card insertion direction
Prevents the card from being damaged in an attempt to remove forcibly
Accidental card fall-out prevention
Suitable for notebook PCs, digital cameras and PDAs
