Eaton, xEnergy MCCB 1P 250A, Breaking Capacity 50 kA, Fixed Mount
- RS Stock No.:
- 537-5551
- Distrelec Article No.:
- 304-00-824
- Mfr. Part No.:
- 259094 NZMN2-A250
- Brand:
- Eaton
Subtotal (1 unit)*
£882.43
(exc. VAT)
£1,058.92
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- Plus 2 unit(s) shipping from 27 October 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £882.43 |
*price indicative
- RS Stock No.:
- 537-5551
- Distrelec Article No.:
- 304-00-824
- Mfr. Part No.:
- 259094 NZMN2-A250
- Brand:
- Eaton
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Eaton | |
| Range | xEnergy | |
| Number of Poles | 1 | |
| Current Rating | 250A | |
| Breaking Capacity at Maximum Voltage Rating | 50 kA | |
| Rated AC Voltage | 690V | |
| Rated DC Voltage | 750V | |
| Mounting Style | Fixed | |
| Length | 105mm | |
| Width | 184mm | |
| Depth | 149mm | |
| Circuit Breaker Type | MCCB | |
| Terminal Contact Type | Screw | |
| Break Time | Instantaneous | |
| Reset Actuator Type | Toggle Switch | |
Select all | ||
|---|---|---|
Brand Eaton | ||
Range xEnergy | ||
Number of Poles 1 | ||
Current Rating 250A | ||
Breaking Capacity at Maximum Voltage Rating 50 kA | ||
Rated AC Voltage 690V | ||
Rated DC Voltage 750V | ||
Mounting Style Fixed | ||
Length 105mm | ||
Width 184mm | ||
Depth 149mm | ||
Circuit Breaker Type MCCB | ||
Terminal Contact Type Screw | ||
Break Time Instantaneous | ||
Reset Actuator Type Toggle Switch | ||
Eaton MCCB, 690V AC Voltage Rating, 250A Current Rating - xEnergy Series - 259094 NZMN2-A250
Protect your people and equipment with this MCCB from Eaton. You can count on it to safeguard sensitive instruments, motors and automation systems against the risk of damage from short circuits and overloads. The circuit breaker has a maximum breaking capacity of 50kA, so it can bear the brunt of strong surges. You'll find this kind of device used in factories, automotive workshops or industrial processing plants to maximise safety.
Features & Benefits
• Rated voltages of 690V AC and 750V DC, so suitable for high-power applications
• Compact dimensions of 105 (L) x 184 (W) x 149mm (D) to slot into crowded setups
• Trips in milliseconds for instant protection
• Screw connection for simple and hassle-free installation
• Wide operating temperature range between -25°C and +70°C
• Compact dimensions of 105 (L) x 184 (W) x 149mm (D) to slot into crowded setups
• Trips in milliseconds for instant protection
• Screw connection for simple and hassle-free installation
• Wide operating temperature range between -25°C and +70°C
Is this MCCB touch-proof?
Yes. It has an IP20 rating, which means that it's protected against accidental touch and objects larger than 12mm.
How does an MCCB work?
An MCCB, or moulded case circuit breaker, contains both thermal and magnetic elements. The physical properties of these cause reactions that break a circuit in overload or short-circuit conditions to cut power to downstream equipment.
Note
Eaton formerly known as Moeller
