Roth Elektronik Single Sided Matrix Board FR4 With 37 x 58 1mm Holes, 2.54 x 2.54mm Pitch, 160 x 100 x 1.5mm
- RS Stock No.:
- 527-9346
- Mfr. Part No.:
- RE220-LF
- Brand:
- Roth Elektronik
Unavailable
RS will no longer stock this product.
Alternative
This product is not currently available. Here is our alternative recommendation.
Each
£4.98
(exc. VAT)
£5.98
(inc. VAT)
- RS Stock No.:
- 527-9346
- Mfr. Part No.:
- RE220-LF
- Brand:
- Roth Elektronik
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Roth Elektronik | |
| Number of Sides | 1 | |
| Hole Pitch | 2.54 x 2.54mm | |
| Dimensions | 160 x 100 x 1.5mm | |
| Length | 160mm | |
| Width | 100mm | |
| Thickness | 1.5mm | |
| Base Material | Epoxy Glass Fabric Laminate | |
| Hole Diameter | 1mm | |
| FR Material Grade | FR4 | |
| Hole Layout | 37 x 58 | |
| Copper Thickness | 35µm | |
| Connection | DIN 41617 | |
Select all | ||
|---|---|---|
Brand Roth Elektronik | ||
Number of Sides 1 | ||
Hole Pitch 2.54 x 2.54mm | ||
Dimensions 160 x 100 x 1.5mm | ||
Length 160mm | ||
Width 100mm | ||
Thickness 1.5mm | ||
Base Material Epoxy Glass Fabric Laminate | ||
Hole Diameter 1mm | ||
FR Material Grade FR4 | ||
Hole Layout 37 x 58 | ||
Copper Thickness 35µm | ||
Connection DIN 41617 | ||
RoHS Status: Exempt
- COO (Country of Origin):
- DE
Matrixboards, DIN 41612//7 Type
Plated through holes (double sided 321//322 types)
Nominal thickness 1.5mm
Copper thickness 35μm
Hole Pitch 2.54mm (0.1 in)
Hole dia 1.0mm
Nominal thickness 1.5mm
Copper thickness 35μm
Hole Pitch 2.54mm (0.1 in)
Hole dia 1.0mm
DIN Type Matrixboard
Matrix boards with 1mm holes on a 2.50mm pitch.
