Samsung2.8 → 3.2 V White LED CSP SMD, LM101A SCP8TT78HPL1T0S06E
- RS Stock No.:
- 122-3600
- Mfr. Part No.:
- SCP8TT78HPL1T0S06E
- Brand:
- Samsung
Currently unavailable
We don't know if this item will be back in stock, RS intend to remove it from our range soon.
- RS Stock No.:
- 122-3600
- Mfr. Part No.:
- SCP8TT78HPL1T0S06E
- Brand:
- Samsung
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | Samsung | |
LED Colours | White | |
Package Type | CSP | |
Mounting Type | Surface Mount | |
Number of LEDs | 1 | |
Forward Voltage | 2.8 → 3.2 V | |
Number of Pins | 2 | |
Viewing Angle | 150 ° | |
Luminous Flux | 56 → 72 lm | |
Lens Shape | Square | |
Forward Current | 350mA | |
Series | LM101A | |
Dimensions | 1.18 x 1.18 x 0.42mm | |
Colour Temperature | 4000K | |
Select all | ||
---|---|---|
Brand Samsung | ||
LED Colours White | ||
Package Type CSP | ||
Mounting Type Surface Mount | ||
Number of LEDs 1 | ||
Forward Voltage 2.8 → 3.2 V | ||
Number of Pins 2 | ||
Viewing Angle 150 ° | ||
Luminous Flux 56 → 72 lm | ||
Lens Shape Square | ||
Forward Current 350mA | ||
Series LM101A | ||
Dimensions 1.18 x 1.18 x 0.42mm | ||
Colour Temperature 4000K | ||
- COO (Country of Origin):
- KR
Samsung LM101A Middle Power LEDs
Compact package size for design flexibility
High degree of reliability with plastic-free structure
Low thermal resistance
LM-80 Certified
High efficiency providing optimised smooth illumination
footprint dimensions: 1.18 x 1.18 mm
High degree of reliability with plastic-free structure
Low thermal resistance
LM-80 Certified
High efficiency providing optimised smooth illumination
footprint dimensions: 1.18 x 1.18 mm
Visible Light LEDs, Samsung
