Mean Well APV-8-5, Constant Voltage LED Driver 7W 5V 0 → 1.4A, APV-8 Series

  • RS Stock No. 881-3970
  • Mfr. Part No. APV-8-5
  • Brand Mean Well
Technical Reference
Legislation and Compliance
RoHS Certificate of Compliance
COO (Country of Origin): CN
Product Details

Mean Well 8W Constant Voltage LED Driver / Power Supply - APV-8 Series

The Mean Well APV-8 series of 8W LED Drivers feature a constant voltage design with universal AC input range from 90 to 264 Vac and single output. These low cost, highly reliable LED power supplies come in a Class II design, without FG pin and have a fully isolated 94V-0 flame retardant plastic enclosure. Suitable uses of the APV-8 series of constant voltage LED drivers include indoor LED lighting, LED decorative lighting, LED office lighting and LED signage.

Constant voltage design
Universal AC input / Full range
Class II power unit, no FG
Fully isolated plastic case
IP30 rating
Small and compact size
Cooling by free air convection
Short circuit, overload and overvoltage protection
No load power consumption ˂0.5W
100% full load burn-in test
Low coast high reliability

Standards

UL8750, CSA C22.2 No.250.0-08; ENEC EN61347-1, EN61347-2-13

Approvals

UL, CSA, EN, CE

Mean Well LED Drivers / Power Supplies

Specifications
Attribute Value
Input Voltage 90 → 264 V ac, 127 → 370 V dc
Output Voltage 5V
Operation Constant Voltage
Output Current 0 → 1.4A
Maximum Output Power 7W
AC or DC Input Voltage Ac, Dc
IP Rating IP30
Configuration Enclosed
Current Rating 150 mA @ 230 V, 300 mA @ 115 V
Number of Outputs 1
Output 5 V @ 1.4 A
Series APV-8
Standards Met CE
Primary Type AC-DC, DC-DC
Voltage Rating 90 → 264 V ac, 127 → 370 V dc
