MEAN WELL LED Driver, 27V Output, 95.85W Output, 3.55A Output, Constant Voltage
- RS Stock No.:
- 660-0375
- Mfr. Part No.:
- CLG-100-27
- Brand:
- Mean Well
Discontinued
- RS Stock No.:
- 660-0375
- Mfr. Part No.:
- CLG-100-27
- Brand:
- Mean Well
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Mean Well | |
| Output Voltage | 27V | |
| Maximum Output Power | 95.85W | |
| Output Current | 3.55A | |
| Dimmable | No | |
| Input Voltage | 127 → 417 V dc, 90 → 295 V ac | |
| Operation | Constant Voltage | |
| LED Driver Type | LED Driver | |
| AC or DC Input Voltage | ac, dc | |
| IP Rating | IP67 | |
| Current Rating | 3.55A | |
| Voltage Rating | 127 → 417 V dc, 90 → 295 V ac | |
| Number of Outputs | 1 | |
| Standards Met | EN 55015, EN 55022 (CISPR22) Class B, EN 55024, EN 61000-3-2 Class C (75% Load), EN 61000-3-3, EN 61000-4-11, EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8, EN 61547 | |
| Select all | ||
|---|---|---|
Brand Mean Well | ||
Output Voltage 27V | ||
Maximum Output Power 95.85W | ||
Output Current 3.55A | ||
Dimmable No | ||
Input Voltage 127 → 417 V dc, 90 → 295 V ac | ||
Operation Constant Voltage | ||
LED Driver Type LED Driver | ||
AC or DC Input Voltage ac, dc | ||
IP Rating IP67 | ||
Current Rating 3.55A | ||
Voltage Rating 127 → 417 V dc, 90 → 295 V ac | ||
Number of Outputs 1 | ||
Standards Met EN 55015, EN 55022 (CISPR22) Class B, EN 55024, EN 61000-3-2 Class C (75% Load), EN 61000-3-3, EN 61000-4-11, EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8, EN 61547 | ||
CLG-100 Series Waterproof (IP67) PFC SMPSU
External, switch mode, encapsulated IP67 rated power supplies
High efficiency, long life and high reliability
Designed for indoor or outdoor installations
Suitable for LED lighting and moving sign applications
Short circuit, over load, over voltage protection
300mm un-terminated, 3-core 18AWG input lead
300mm un-terminated, 2-core 18AWG output lead
UL1310 Class 2, LPS
EMC compliance to EN 55022 Class B
Power factor correction to EN 61000-3-2
High efficiency, long life and high reliability
Designed for indoor or outdoor installations
Suitable for LED lighting and moving sign applications
Short circuit, over load, over voltage protection
300mm un-terminated, 3-core 18AWG input lead
300mm un-terminated, 2-core 18AWG output lead
UL1310 Class 2, LPS
EMC compliance to EN 55022 Class B
Power factor correction to EN 61000-3-2
Note
For Industrial Use Only, not in scope of Regulation (EC) No 125/2009.
Power derates above 50°C.
MTBF to MIL-HDBK-217F.
Power derates above 50°C.
MTBF to MIL-HDBK-217F.
Standards
TUV EN 60950-1, EN 61347-1, EN 61347-2-13, UL 1310 Class 2, UL 879, CAN/CSA C22.2 No. 223-M91 (except for 48 V)
Approvals
TUV, UL recognised for Canada & US
