STMicroelectronics STEVAL-ILL064V1, Evaluation Board for LED5000
- RS Stock No.:
- 875-0854
- Mfr. Part No.:
- STEVAL-ILL064V1
- Brand:
- STMicroelectronics
Subtotal (1 unit)*
£28.33
(exc. VAT)
£34.00
(inc. VAT)
Stock information currently inaccessible
Units | Per unit |
|---|---|
| 1 + | £28.33 |
*price indicative
- RS Stock No.:
- 875-0854
- Mfr. Part No.:
- STEVAL-ILL064V1
- Brand:
- STMicroelectronics
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | STMicroelectronics | |
| Kit Classification | Evaluation Board | |
| Featured Device | LED5000 | |
Select all | ||
|---|---|---|
Brand STMicroelectronics | ||
Kit Classification Evaluation Board | ||
Featured Device LED5000 | ||
3A LED Driver (LED5000 in BB- Boost Topology), STMicroelectronics
The STEVAL-ILL063V1 is an Evaluation Board based on the LED5000, a step-down current source with dimming capability. The adjustable output current is 3A DC maximum. A sensing resistor on the feedback pin sets the regulated output current level. The board is fully protected against over-heating, over-current and output short-circuit.
5.5V to 48V operating input voltage range
850kHz fixed switching frequency
200mV typ. current sense voltage drop
BB- boost topology
PWM dimming
±3% output current accuracy over temperature
200mOhm typical RDS(ON)
Compliant with ceramic output capacitors
Inhibit for zero current consumption
Thermal shutdown
850kHz fixed switching frequency
200mV typ. current sense voltage drop
BB- boost topology
PWM dimming
±3% output current accuracy over temperature
200mOhm typical RDS(ON)
Compliant with ceramic output capacitors
Inhibit for zero current consumption
Thermal shutdown
LED Drivers, Lighting ICs, STMicroelectronics
