Vishay 10 μH ±20% Leaded Inductor, Max SRF:7.76MHz, 33A Idc, 3.64mΩ Rdc, IHTH-1125KZ-5A
- RS Stock No.:
- 123-1541
- Mfr. Part No.:
- IHTH1125KZEB100M5A
- Brand:
- Vishay
1 In stock - FREE next working day delivery available
Added
Price Each
£6.33
(exc. VAT)
£7.60
(inc. VAT)
| Units | Per unit |
| 1 - 9 | £6.33 |
| 10 - 24 | £4.92 |
| 25 - 49 | £4.78 |
| 50 - 99 | £4.66 |
| 100 + | £4.54 |
- RS Stock No.:
- 123-1541
- Mfr. Part No.:
- IHTH1125KZEB100M5A
- Brand:
- Vishay
Technical Reference
Legislation and Compliance
- COO (Country of Origin):
- MX
Product Details
IHTH1125 Series High Current Through Hole, High Temperature Inductors
IHTH Series high current through hole, high temperature inductors for automotive applications. These inductors have a shielded construction and have excellent DC/DC energy storage up to 1MHZ. The IHTH inductors handle high translent current spikes without saturation, they also have an ultra low buzz noise, due to composite construction.
The IHTH high current inductors come with 2 pins 0.47uH to 47uH and 3 pins 68uH to 100uH pins.
The IHTH high current inductors come with 2 pins 0.47uH to 47uH and 3 pins 68uH to 100uH pins.
Applications
Diesel injection drivers
Engine and transmission control units
DC/DC Convertors for entertainment/ navigation systems
Noise suppression for motors
- Windshield wipers
- Power seats
- Power mirrors
- HID lighting
- Heating and ventilation blowers
LED drivers
Engine and transmission control units
DC/DC Convertors for entertainment/ navigation systems
Noise suppression for motors
- Windshield wipers
- Power seats
- Power mirrors
- HID lighting
- Heating and ventilation blowers
LED drivers
Standards
AEC-Q200 qualified
Vishay Non Standard SMT Inductors (Chokes)
Specifications
Attribute | Value |
|---|---|
| Inductance | 10 μH |
| Maximum DC Current | 33A |
| Mounting Type | Radial |
| Maximum DC Resistance | 3.64mΩ |
| Tolerance | ±20% |
| Diameter | 28.5mm |
| Height | 10.7mm |
| Dimensions | 28.5 (Dia.) x 10.7mm |
| Maximum Self Resonant Frequency | 7.76MHz |
| Lead Pitch | 17.8mm |
| Series | IHTH-1125KZ-5A |
| Terminal Type | Through Hole |
| Lead Diameter | 1.8mm |
| Minimum Operating Temperature | -55°C |
| Maximum Operating Temperature | +155°C |
- RS Stock No.:
- 123-1541
- Mfr. Part No.:
- IHTH1125KZEB100M5A
- Brand:
- Vishay
